Check Valve Specifications
Style: Piston Check Valve with embedded O-ring that seals on seat
Maximum operating pressure: 500 PSI (34.5 bar)
Maximum operating temperature: 180 °F (82 °C)
Cracking Pressure: 1 PSI
Material: Brass Body and Piston, Beryllium Copper Ring
Shut-Off Valve Specifications
Function: 2-Way Normally Closed
Ports: ¾” NPT
Pressure Range: 2 PSI to 150 PSI (0.14 bar to 10 bar)
Temperature Ratings:
Ambient: 14 F to 122 F (-10 C to 50 C)
Fluid Media: 176 F (80 C) Maximum
Coil Power Rating: 24VDC @ 700 mA (16 Watts) Maximum
Electrical Connector: DIN Style Plug w/ Removable Cable Plug Adaptor
Materials of Construction:
Body: Brass
Seal: Buna N
Other Wetted Parts: Stainless Steel, PVDF, Brass
Coil: Class F, Molded, Continuous Duty, UL & CSA Listed
Contact Factory for Spare Parts
Manual Override (Bypass)
Normal Operation
Manual Override
Position - 90 Degrees
ONLY!
KIP/NORGREN VALVE PARKER VALVE
