GENERAL SPECIFICATION
Maximum Operating Pressure: 150 PSI (10 bar)
Minimum Operating Pressure: 10 PSI of back pressure is required for the formation of vortices.
Temperature Ratings:
Ambient: 14 F to 122 F (-10 C to 50 C)
Fluid Media: 176 F (80 C) Maximum
Flow Rate: 0.35 GPM Min. to 6.0 GPM Max. (22.7 LPM)
Flow Measurement Accuracy: ± 2% full-scale (± 0.2 LPM)
Repeatability: 0.25% of actual flow
Power Requirement: 24 VDC @ 750 mA (18 Watts) Maximum (Solenoid Valve energized)
Alarm Output: 24V = Fault, 0V = OK
Alarm Output Impedance: 2K Ohms (internal pull-up resistor)
Electrical Connection: Turck EURO FS4.6
Wetted Parts: Brass, PVDF, Viton, Buna N (NBR), EPDM, FKM, Beryllium Copper
Caution: The unit shall be supplied by a SELV (separated extra-low voltage) source in
accordance with CSA Standard C22.2 No.1010.1-92 Annex H.
Environmental conditions: This device has been designed for use in Installation Category I,
pollution degree 4, at altitudes up to 2000 meters (6560 ft.),
either indoors or outdoors as defined in CSA Standard C22.2
No.1010.1-92.
