3. Rotate the Alpha Dial to obtain the desired volume level. Note: An Audio Save
may be performed to save this setting as the default. Please refer to the “Audio
Save” section.
AUDIO SAVE
Changes made to audio settings are temporary and are lost when the organ is turned off
unless those settings are saved. This can be done by performing the following procedure.
SAVING AUDIO CONTROL SETTINGS:
1. While in any Audio Menu, hold SET, then press and hold General Cancel for
approximately five seconds.
2. Continue holding both pistons until the Console Display reads:
A U D I O C O N T R O L
S E T T I N G S S A V E D
3. Release SET and General Cancel.
Any changes made to any audio control settings are saved when the organ is turned off.
STEREO HEADPHONE JACK
The console is equipped with a 1/4" stereo headphone jack located near the power switch
on the left panel. Plugging a set of headphones into this jack disables the sound from all
speakers, and disables any pipe ranks connected to the instrument. When using headphones,
the “MASTER VOLUME” menu is replaced with the “HEADPHONE” menu. This menu
allows the adjustment of Volume, Balance, Bass, and Treble heard through the headphones.
These adjustments do not affect the organ speakers in normal playing mode. Note: Please
refer to the “835 User (Headphone) Menu Items”section.
ADJUSTING THE HEADPHONE SETTINGS:
1. Press and hold SET.
2. Rotate the Select Knob counter clockwise (left) until the Console Display reads
“HEADPHONE”, and place the cursor on the top line.
3. Release SET.
4. Rotate the Alpha Dial to select the setting to be adjusted (“VOLUME”,
“BALANCE”, “BASS”, or “TREBLE”).
5. Turn the Select Knob clockwise (right) to place the cursor on the bottom line.
6. Rotate the Alpha Dial to set the desired value.
AUXILIARY INPUTS
The Rodgers 835 is equipped with stereo Auxiliary Input Jacks (one for the left channel
and one for the right channel) located on the Connector Panel under the keydesk to the right.
