Chapter 1
12
FRONT PANEL DESCRIPTION
1 Power Switch
This switch turns the W-5000 on and off.
2 Tweeters
These are high-frequency speakers.
1 2 3 4 6 7 8 2
5
9 10 11 12 13 14 15 16 17 18 19
20
21
22
