Roger Technology H70/101AC User Manual

SELECTION BUTTON SCROLLING BUTTON
DISPLAY INPUT
17
MOTOR COURTESY F N POWER 230Vac
CAPACITOR FLASHING LIGHT
Encoder
POWER Step by step Stop Release
Radio receiver
Limit switch2 Limit switch1
Open Close Pedestrian Clock
H70/101AC
picture 4
S2 +
S3
MECHANICAL
RELEASE
INPUT
LIMIT
SWITCH
INPUT
ENCODER
INPUT
COM - COMMON
AP - OPEN
CH - CLOSE
PED - PEDESTRIAN
ORO - CLOCK
S1 -
ANT - ANTENNA
COM - COMMON
PP - STEP BY STEP
ST - STOP
COS1 - SAFETY EDGE 1
COS2 - SAFETY EDGE 2
FT1 - PHOTOCELL 1
FT2 - PHOTOCELL 2
COM - COMMON
SC - OPEN GATE LED . 24Vcc
24V - ACCESSORIES POWER
24Vcc MAX 300mA
Fuse 0,5A FAST
Fuse 6,3A FAST
picture 5
Safety edge1
Safety edge 2
