PULSANTE SELEZIONE PULSANTI SCORRIMENTO
RAPPRESENTAZIONE INGRESSI SUL DISPLAY
9
COM - COMUNE
AP - APRI
CH - CHIUDI
PED - PEDONALE
ORO - OROLOGIO
ANT - ANTENNA
COM - COMUNE
PP - PASSO PASSO
ST - STOP
COS1 - COSTOLA 1
COS2 - COSTOLA 2
FT1 - FOTOCELLULA 1
FT2 - FOTOCELLULA 2
COM - COMUNE
SC -
SPIA CANC. AP. 24Vcc
24V -
ALIM. ACCESSORI
24Vcc MAX 300mA
connettore RADIO
Fusibile 0,5A FAST
Fusibile 6,3A FAST
MOTORE CORTESIA F N ALIM. 230Vac
CONDENSATORE LAMPEGGIANTE
S3
S2 +
Figura 4
Figura 5
H70/101AC
Ingresso
SBLOCCO
meccanico
Ingresso
FINECORSA
Ingresso
ENCODER
S1 -
ENCoder
POWER PassoPasso STop SBlocco
COStola1
COStola2
FoTo1
FoTo2
FineCorsa2 FineCorsa1
APri CHiudi PEDonale OROlogio
