10. If the controller is supposed to operate with PRT series and/or Wiegand readers then activate them
11. Optionally enter comments for controller objects to facilitate their identification during further
configuration of the system.
12. Optionally make a backup by clicking Send to File…
13. Click Send to Device to update the configuration of the controller an disconnect selecting Device in the
top menu and then Disconnect.
Note: In case of modifying low level configuration for controller which is operated in existing installation,
additionally start VISO software detect again the controller, replace and synchronise settings according to
AN015 application note.
Table 4. Low level configuration parameters
Communication
IP address
Device IP address.
Default gateway
Gateway IP address.
Subnet mask
Subnet mask.
RS485 answer timeout [ms]
Parameter defines maximal delay for peripheral device response on
RS485 bus. Range: 25-500. Default value: 250.
RS485 encryption
Parameter enables encryption on RS485 bus. Range: [0]: No, [1]:
Yes. Default value: [0]: No.
RS485 encryption key
Parameter defines key for encryption of communication at RS485
bus. Range: 4-16 ASCII characters.
RACS CLK/DTA readers
Terminal 1 (RACS CLK/DTA ID0)
Parameter enables PRT series reader with ID=0 address. Range: [0]:
OFF, [1]: ON. Default value: [0]: OFF.
Terminal 2 (RACS CLK/DTA ID1)
Parameter enables PRT series reader with ID=1 address. Range: [0]:
OFF, [1]: ON. Default value: [0]: OFF.
Terminal 3 (RACS CLK/DTA ID2)
Parameter enables PRT series reader with ID=2 address. Range: [0]:
OFF, [1]: ON. Default value: [0]: OFF.
Terminal 4 (RACS CLK/DTA ID3)
Parameter enables PRT series reader with ID=3 address. Range: [0]:
OFF, [1]: ON. Default value: [0]: OFF.
Wiegand readers
Terminal 5 (Wiegand 1)
Parameter enables Wiegand reader on IN1/IN2 inputs. Range: [0]:
OFF, [1]: ON. Default value: [0]: OFF.
Terminal 6 (Wiegand 2)
Parameter enables Wiegand reader on IN3/IN4 inputs. Range: [0]:
OFF, [1]: ON. Default value: [0]: OFF.
Terminal 7 (Wiegand 3)
Parameter enables Wiegand reader on IN5/IN6 inputs. Range: [0]:
OFF, [1]: ON. Default value: [0]: OFF.
Terminal 8 (Wiegand 4)
Parameter enables Wiegand reader on IN7/IN8 inputs. Range: [0]:
OFF, [1]: ON. Default value: [0]: OFF.
Wiegand format
Parameter defines data format from Wiegand readers. Range: [0]:
Auto, [1]: Without control bits, [2]: Without extreme bits, [3]: With
control bits. Default value: [0]: Auto.
Terminal settings
Terminal 1-8: Type and class
Parameter defines type and class of authentication factor returned by
terminal. Default value: 0x00100001.
Terminal 1-8: Keypad type
Parameter defines terminal keypad type. Range: [0]: OFF, [1]: Digits,
[2]: Digits 2F, [3]: Digits 4F, [4]: PIN only. Default value: [4]: Only PIN.
