Terminal 1-8: Keypad timeout
Parameter defines terminal keypad timeout. Range: 0-10000. Default
value: 10000.
Input types
IN1-IN8
Parameter defines type of input lines. Range: [1]: NO, [2]: NC, [3]:
EOL/NO, [4]: EOL/NC, [5]: 2EOL/NO, [6]: 2EOL/NC, [7]: 3EOL/NO,
[8]: 3EOL/NC, [9]: 3EOL/DW/NO, [10]: 3EOL/DW/NC. Default value:
[1]: NO.
Input response times
IN1-IN8 [ms]
Parameter defines minimal duration of pulse which is required to
trigger the input. Range: 50-5000. Default value: 300.
Parametric (EOL) input resistances
Tamper [Ohm]
Parameter defines Tamper resistor for parametric (EOL) inputs.
Default value: 1k.
Alarm A [Ohm]
Parameter defines Alarm A resistor for parametric (EOL) inputs.
Default value: 2.2k.
Alarm B [Ohm]
Parameter defines Alarm B resistor for parametric (EOL) inputs.
Default value: 5.6k.
Output reversed polarity
OUT-OUT6, REL1, REL2, CLK,
DTA
Parameter defines default output status. Range: [0]: No, [1]: Yes.
Default value: [0]: No.
Output functions
OUT1-OUT6, REL1, REL2, CLK,
DTA
Parameter defines output function which can be used to control
Wiegand terminal.
Advanced settings
Battery test period [s]
Parameter defines time between successive battery tests. Default
value: 600
AC lost delay [s]
Parameter defines time after which lost AC supply is reported.
Default value: 300.
Device comments
DEV comment
Parameter defines any text or comment which corresponds to the
device. It is later displayed in VISO program.
Configuration ID
Unique number which corresponds to current low level configuration
of device.
Power supply comments
PWR
Parameter defines any text or comment which corresponds to the
object. It is later displayed in VISO program.
Terminal comments
Terminal 1-8
Parameter defines any text or comment which corresponds to the
object. It is later displayed in VISO program.
Input comments
IN1-IN8
Parameter defines any text or comment which corresponds to the
object. It is later displayed in VISO program.
Output comments
OUT1-OUT6, REL1, REL2, CLK,
DTA
Parameter defines any text or comment which corresponds to the
object. It is later displayed in VISO program.
