MC16 Operating Manual 09.01.2020
Tab T&A Options
Parameter Default T&A Mode – specifies default Time and Attendance Mode at the Access Point.
Parameter T&A Mode Schedule – enables assignment of schedule to specify T&A Modes for the Access
Point in various periods. It requires earlier defining of Time and Attendance type Schedule.
Option Register T&A Event when physical access is granted – when the option is enabled then every
access granting will additionally generate Time and Attendance event if a user is assigned with Advanced
Authorisation for the function [155].
Tab Advanced Options
Parameter Thread Level – specifies access level at the Access Point. If Thread Level of Access Credential
belonging to particular user is lower than Thread Level of Access Point then access is denied regardless of
Authorisation assigned to user’s Access Credential.
Option Cancel Door Open Too Long Alarm after access is granted – when the option is enabled then
controller cancels Door Open Too Long Alarm when access is granted at the door.
Option Cancel Door Forced Open Alarm after access is granted – when the option is enabled then
controller cancels Door Forced Open Alarm when access is granted at the door.
Option Access must be followed by door opening – when the option is enabled then user entry into
Access Zone is counted only if access granting is followed by actual door opening which is confirmed by
door contact connected to controller input with the function [130]. The option concerns such Access Zone
functionalities as anti-passback (APB), occupancy count and neighboring zones.
Option Two Users Mode – when the option is enabled then access can be granted only if two Access
Credentials with adequate Authorisations are used at the Access Point.
Option Deny access on random personal check – when the option is enabled then in case of randomly
selected user not only output with the function [89] is activated but additionally access is denied at the
Access Point.
Parameter Access Direction – specifies the direction of user movement when access is granted at the
Access Point. The parameter is used mainly in turnstile control which is explained in AN019 application
note. Available values:
None – parameter disabled.
Read-in – when access is granted at the Access Point then outputs with functions [037] and [035]
are activated.
Read-out – when access is granted at the Access Point then outputs with functions [038] and [036]
are activated.
Read-in/out – when access is granted at the Access Point then outputs with functions [037], [038,
[035] and [036] are activated.
Parameter Card Holder Location – enables to indicate which Access Terminal of the Access Point is
equipped with card holder so Login Options which require card holder could be used. Terminals with card
holders (e.g. MCT82M-IO-CH) are mainly used in hotel application to control power supply in a room.
Parameter Buzzer Signalization Priority – specifies priority in range of 1-16 for BUZZER output control by
terminal’s internal logic. BUZZER output can be also assigned with output function(s) by system
administrator and it is possible to define priority for such function(s). Therefore the parameter enables to
decide if administrator defined logic or internal logic has priority in BUZZER control. The higher the number
the higher the priority.
Tab Login Options
The tab is available when an Access Point is created and it enables to define parameters for Normal Login
(single use of Authentication Factor), Special Login (long card reading), Double Login (double use of
Authentication Factor) and for card inserting and removing from holder. Configuration parameters for each
login option are the same.
Parameter Action Type – specifies action type for particular login option. Available types are function and
Local Command.
Parameter Action – specifies the function or Local Command which will be started by user for particular
login option.
Parameter Parameter – specifies a parameter for the function of action. As an example, for the function
[153]: Set Momentary T&A Mode the parameter is particular T&A Mode. The parameter is not configured in
this field when Local Command is applied.
