MC16 Operating Manual 09.01.2020
Area General
Parameter Local Command – enables to select Local Command object.
Parameter Function – enables to select function for the command. The list of all available functions is given
in the table 5 below.
Parameter Parameter – specifies parameter of selected function. It is available for some functions only.
Option Register Action Event – when the option is enabled then command triggering generates event
related to command function.
Parameter Logic Function – not used for Local Command.
Area Authentication and Authorisation Options
Option User authentication required – when the option is enabled then users can use the command
without Authorisation(s) assigned. It is enough that such users are equipped with Authentication Factors
which are enrolled in the system.
Option Authorisation for Access Point required – when the option is enabled then only users with proper
Authorisation can use the command. The Authorisation must include Access Point type Positive rule for the
Access Point where the command is started.
Option Authorisation for Object required – when the option is enabled then only users with proper
Authorisation can use the command. The Authorisation must include Object type Positive rule for the object
where command is configured (e.g. Access Door).
Option Authorisation for Function Parameter required – when the option is enabled then users with
proper Authorisation can use the key. The Authorisation must include Parameter type Positive rule for the
parameter of the function triggered by command.
Local Commands functions
Local Command functions are available within selected objects. For example, command can be used for
arming/disarming and then it should be configured on the level of Alarm Zone. Function Key functions are
the same as Input functions (table 5) except for Power Supply object functions and toggle (status) type
functions.
Outputs
Output represents object dedicated to control external electric device. Output function specifies situation
(event) when output is triggered (e.g. door lock release as a result of access granting). The function can
trigger output with various modulations. One or more functions can be assigned to single output. When
multifunction output is applied then its triggering may be started by multiple actions in the system according
to their priorities.
Area General
Text box Name – enables to name the output.
Text box Description – enables to enter custom description for the output.
Area Object
Parameter Name – enables selection of physical output.
Info box Device – specifies device with selected output.
Info box Label – specifies type of object.
Info box Comment – displays comment which was assigned to the output during low level configuration.
Info box Type – specifies type of output.
Info box IP Address – specifies IP address of host device (controller).
Info box RS Address – specifies RS485 address of device with the output.
Area Additional Options
Parameter Activity Schedule – enables assignment of schedule to specify when output can be triggered. It
requires earlier defining of General Purpose Maintained type Schedule.
Parameter Reset Schedule – enables assignment of schedule to specify when output will be released (if
triggered). It requires earlier defining of General Purpose Momentary type Schedule.
Option Multifunction – when the option is enabled then it is possible to specify the maximal number
functions for assignment to the output.
