MC16 Operating Manual 09.01.2020
31/52
Parameter Function Limit – specifies the maximal number of functions for assignment to the output.
Output object can be further configured, mainly in regard of its function on the level of other objects e.g.
Access Door. Other parameters for such configuration are given below, while parameters specific for
particular function are explained in the description of such function in the table 6.
Area General
Parameter Output – enables to select Output object.
Parameter Function – enables to select function for the Output. The list of all available functions is given in
the table 6 below.
Area Triggering Options
Parameter Priority – specifies priority of function for multifunction output. The function with higher priority
controls the output and overrides current signalling at the output.
Parameter Triggering Method – specifies method of output triggering. Available values:
 Set output ON for period of time – output is triggered for time specified by the parameter Pulse
Time.
 Set output ON for unlimited time – output is triggered indefinitely.
 Set output OFF – output is released indefinitely.
Parameter Pulse Time – specifies total triggering time for Set output ON for period of time triggering
method.
Parameter Unit – specifies time unit for Pulse Time parameter.
Area Modulation Options
Parameter Type – specifies output modulation e.g. one short pulse repeated every 1s.
Parameter Frequency – specifies frequency of modulation when Custom type is selected.
Parameter Pattern – specifies pattern of modulation when Custom type is selected.
Parameter Number of Cycles – specifies number of pattern repetitions when Custom type is selected.
Area Function Parameter
Enables selection of parameter for some of output functions e.g. Schedule for function [017], intensity for
function [089], etc.
Output functions
Output functions are available within selected objects. For example, output line can be used to control door
lock and then it should be configured on the level of Access Door.
Output functions are divided into event type which are triggered by state/event and status type which reflect
particular state from trigger moment to release moment.
