Roger MC16 - Page 32

MC16 Operating Manual 09.01.2020
32/52
Table 6 Output functions
No.
Name
Type
Object
Description
1
Low Battery Status
Status
Power Supply
Triggered as long as low battery is detected.
2
Low Battery ON
Event
Power Supply
Triggered when low battery is detected.
3
Low Battery OFF
Event
Power Supply
Triggered when low battery is no longer detected.
4
Battery Failure Status
Status
Power Supply
Triggered as long as battery failure is detected.
5
Battery Failure ON
Event
Power Supply
Triggered when battery failure is detected.
6
Battery Failure OFF
Event
Power Supply
Triggered when battery failure is no longer detected.
7
AC Lost Status
Status
Power Supply
Triggered as long as 18VAC power supply is lost.
8
AC Lost ON
Event
Power Supply
Triggered when AC power supply lost is detected.
9
AC Lost OFF
Event
Power Supply
Triggered when AC power supply lost is no longer detected.
10
Delayed AC Lost Status
Status
Power Supply
Triggered as long as delayed AC power supply is lost.
11
Delayed AC Lost ON
Event
Power Supply
Triggered when delayed AC power supply lost is detected.
12
Delayed AC Lost OFF
Event
Power Supply
Triggered when delayed AC power supply lost is no longer detected.
13
Power Supply Overload Status
Status
Power Supply
Triggered as long as power supply unit overload is detected.
14
Power Supply Overload ON
Event
Power Supply
Triggered when power supply unit overload is detected.
15
Power Supply Overload OFF
Event
Power Supply
Triggered when power supply unit overload is no longer detected.
16
Calendar Status
Status
Main Board
Triggered on days specified by assigned Calendar. It requires earlier defining
of Calendar.
17
Schedule Status
Status
Main Board
Triggered for time periods specified by assigned Schedule. It requires earlier
defining of General Purpose Maintained type Schedule.
18
Schedule ON
Event
Main Board
Triggered when schedule period/moment starts. It requires earlier defining of
General Purpose Maintained type Schedule or General Purpose Momentary
type Schedule.
19
Schedule OFF
Event
Main Board
Triggered when schedule period ends. It requires earlier defining of General
Purpose Maintained type Schedule.
20
Controller Start
Event
Main Board
Triggered when MC16 controller is started.
21
Node Status
Status
Automation
Triggered as long as Automation Node is switched on.
