specified by the parameter Upper Limit.
53
Occupancy Lower Limit ON
Event
Access Zone
Triggered when the number of users in Access Zones reaches value
specified by the parameter Lower Limit.
54
No Users in Access Zone ON
Event
Access Zone
Triggered when the last user leaves Access Zone.
55
No Users in Access Zone Status
Status
Access Zone
Triggered as long as there are no users in Access Zone.
56
Occupancy Upper Limit Status
Status
Access Zone
Triggered as long as the number of users in Access Zone reaches the value
specified by the parameter Upper Limit.
57
Occupancy Lower Limit Status
Status
Access Zone
Triggered as long as the number of users in Access Zone reaches the value
specified by the parameter Lower Limit.
58
Tamper Status
Status
Main Board
Triggered as long as Tamper Alarm is raised by input function [133].
59
Tamper ON
Event
Main Board
Triggered when Tamper Alarm is raised by input function [133].
61
T&A Event Registered
Event
Access Point
Triggered when Time&Attendance event is registered at Access Point.
62
Elevator Problem Status
Status
Access Point
Triggered as long as problem with elevator control is detected. The function is
available only for MC16-EVK controllers.
63
Elevator Called
Event
Access Point
Triggered when elevator is called. The function is available only for MC16-
EVK controllers.
64
Access Point Bell
Event
Access Point
Triggered when door bell is activated at Access Point i.e. input with the
function [159] is triggered.
65
LED SYSTEM Status
Status
Access Point
Triggered as long as LED SYSTEM (orange) indicator on one of terminals
belonging to the Access Point is switched on. By default the indicator is used
to signal various system functions including reader error.
66
LED OPEN Status
Status
Access Point
Triggered as long as LED OPEN (green) indicator on one of terminals
belonging to the Access Point is switched on. By default the indicator is used
to signal access granting at Access Point.
67
LED ARMED Status
Status
Access Point
Triggered as long as LED ARMED (red) indicator on one of terminals
belonging to the Access Point is switched on. By default the indicator is used
to signal that Access Point belongs to armed Alarm Zone.
68
LED DISARMED Status
Status
Access Point
Triggered as long as LED DISARMED (green) indicator on one of
terminals belonging to the Access Point is switched on. By default the
indicator is used to signal that Access Point belongs to disarmed Alarm Zone.
69
BUZZER Status
Status
Access Point
Triggered as long as buzzer on one of terminals belonging to the Access
Point is switched on. By default the buzzer is used to signal access granting,
