the parameter Read-out or Read-in/out. The function is mainly used to control
read-in/out portal such as turnstile, gate, etc. Contrary to function [38] it is
used to control by means of status.
37
Read-in Door Lock
Event
Access Door
Triggered when access is granted by user identification at Access Point with
the parameter Read-in or Read-in/out. The function is mainly used to control
read-in/out portal such as turnstile, gate, etc. Contrary to function [35] it is
used to control by means of pulse.
38
Read-out Door Lock
Event
Access Door
Triggered when access is granted by user identification at Access Point with
the parameter Read-out or Read-in/out. The function is mainly used to control
read-in/out portal such as turnstile, gate, etc. Contrary to function [36] it is
used to control by means of pulse.
39
APERIO Door Lock
Event
Access Door
Triggered when access is granted. The function is dedicated to Aperio (ASSA
ABLOY) wireless lock.
41
Armed ON Mode Status
Status
Alarm Zone
Triggered as long as Alarm Zone is armed. The function operates inversely to
function [47].
42
Armed ON Mode
Event
Alarm Zone
Triggered when Alarm Zone is armed.
43
Armed OFF Mode
Event
Alarm Zone
Triggered when Alarm Zone is disarmed.
44
Armed ON/Armed OFF Mode
Event
Alarm Zone
Triggered when Alarm Zone is armed or disarmed.
45
Armed ON Mode Request
Event
Alarm Zone
Triggered when request to arm is started by means of input function [107] or
[109].
46
Armed OFF Mode Request
Event
Alarm Zone
Triggered when request to disarm is started by means of input function [108]
or [109].
47
Armed ON/ArmedOFF Mode
Request
Event
Alarm Zone
Triggered when request to arm or disarm is started by means of input
function [107], [108] or [109].
48
Armed OFF Mode Status
Status
Alarm Zone
Triggered as long as Alarm Zone is disarmed. The function operates
inversely to function [41].
49
Intruder Alarm Status
Status
Alarm Zone
Triggered as long as Intruder Alarm is signalled. The alarm is started by input
function [220] or [221] for the time specified by Alarm Zone parameter Alarm
Time [s].
50
Intruder Alarm ON
Event
Alarm Zone
Triggered when Intruder Alarm is raised by input function [220] or [221].
51
Anti-passback Violation
Event
Access Zone
Triggered when Anti-passback rules are violated by a user at Access Point.
52
Occupancy Upper Limit ON
Event
Access Zone
Triggered when the number of users in Access Zones reaches value
