Roger PR301 - User Programming; Installer Programming

PR_041_UK.cdr
FUNCTIONI [1] ; [2] - OPTION
[0] input off
[1] NO/Door open sensor (DC)
[2] NC/Door open sensor (DC)
[3] NO/Exit button (DR)
[4] NC/Exit button (DR)
[5] NO/Input control ON/OFF mode
[6] NC/Input control ON/OFF mode
THE OPTIONS AVAILABLE IN INSTALLER PROGRAMMING MODE
FUNCTION [4] - OPTION
[0] The DUAL identification mode off
[1] The DUAL identification mode for : NORMAL
[2] . : MASTER
[3] : NORMAL + MASTER
[4] : SWITCHER
[5] : NORMAL + SWITCHER
[6] : MASTER + SWITCHER
[7] : NORMAL + MASTER + SWITCHER
The DUAL identification mode for
The DUAL identification mode for
The DUAL identification mode for
The DUAL identification mode for
The DUAL identification mode for
The DUAL identification mode for
FUNCTION [5] - OPTION
[0] The bistable output (repeats ON/OFFmode of the controller)
[1] The output signalizes the condition : PREALARM
[2] The output signalizes the condition : DOOR OPEN
[3] The output signalizes the condition : PREALARM + DOOR OPEN
[4] The output signalizes the condition : FORCED ENTRY
[5] The output signalizes the condition : PREALARM + FORCED ENTRY
[6] The output signalizes the condition : DOOR OPEN + FORCED ENTRY
[7] The output signalizes the condition : PREALARM + DOOR OPEN + FORCED ENTRY
FUNCTION [6] - OPTION
[PQ] = 01 ... 99 - time for entry
[RS] = 01 ... 99 - delay before DOOR AJAR alarm
FUNCTION [7] - OPTION
[ID] = 00 ... 99 - the controller ID number
FUNCTION [3] - OPTION
[0] A, B and C options are off
[1] A
[2] B
[3] A + B
[4] C
[5] A + C
[6] B + C
[7] A+B+C
OPTION A: “Reprograming disable”; The option disabling programing
(local or download) of the controller in future.This option can
only deleted by RESET of the EEPROM memory.
OPTION B: “Access can be granted only in On mode” - door
can only be opened when controller is in the ON mode
OPTION C: “Bad identifier timed lock-out”; Reading of identifier
is blocked for 1 minute after three consecutive attem
pts of entring an unknown identifier repeated in period
shorter than 1 minute.
IN 1 INPUT FUNCTION
[1] + [OPTION]
IN 2 INPUT FUNCTION
[2] + [OPTION]
SPECIAL OPTIONS
[3] + [OPTION]
USERS IDENTIFICATION MODES
[4] + [OPTION]
FUNCTION OF OUTPUT ALARM
[5] + [OPTION]
PROGRAMMING
CONTROLLER IDENTIFICATION NUMBER
[7] + [ID]
PROGRAMMING
OF “INSTALLER” IDENTIFIER
[8] + [“INSTALLER” code ] [#] +
[“INSTALLER” code ] [#] + [“INSTALLER” card ]
PROGRAMMING
OF “MASTER” IDENTIFIER
[9] + [“MASTER” code ] [#] +
[“MASTER” code ] [#] + [“MASTER” card ]
PROGRAMMING OF OPENING TIME
AND TIME FOR CLOSING
[6] + [PQ] + [RS]
INSTALLER
PROGRAMMING
ON/OFF
OPEN
SYSTEM
MULTIPLAY ADDING OF ”NORMAL” USERS
[4]+[card1] +...+[cardn]+[#]
MULTIPLAY ADDING OF “SWITCHER” USERS
[5]+[card1] +...+[cardn]+[#]
DELETES USERS WITH ENTERED
CARD OR CODE
[6] [code] [#]
[6] [card]
DELETES ALL “NORMAL” AND ”SWITCHER”
USERS
[7]+[#]+[7]+[#]
ENTRY TO THE
“INSTALERS” PROGRAMMING MODE
[8] + [“INSTALLER” code ] [#]
[8] + [“INSTALLER” card ]
EXIT FROM PROGRAMMING MODE
[0]+[#]
DELETE USER NO ...
[3] + [xyz]
ADD “NORMAL” USER
[1]+[xyz]+[#]+[xyz]+[#]+
[code] + [#] + [code] + [#] + [card]
ADD “SWITCHER” USER
[2]+[xyz]+[#]+[xyz]+[#]+
[code] + [#] + [code] + [#] + [card]
USER
PROGRAMMING
ON/OFF
OPEN
SYSTEM
AUTOMATICALLY AFTER 3 MINUTES
WHEN NO OPERATION
Exit from PROOGRAMMING MODE
Entry
to the
MODE
-
USER
PROGRAMING
AUTOMATICALLY AFTER 3 MINUTES
WHEN NO OPERATION
EXIT FROM PROGRAMMING MODE
[0]+[#]
