Installer Programming mode
In the Installer programming mode detailed setup of controller is available. Entry to the installer programming mode can be done only
from the User Programming mode by activation of function [8]. After entry to the Installer Programming mode the SYSTEM and
CLOSED LED are on. A programming function is activated by giving its number (0, 1 … 9 ). After activation of the function, LEDs starts
blink. The following functions are available:
[1] - IN1
INPUT FUNCTION
[1]
+ [OPTION]
[0] ⇒ Input off.
[1] ⇒ NO / Door open sensor (DC)
[2] ⇒ NC / Door open sensor (DC)
[3] ⇒ NO / Exit button (DR)
[4] ⇒ NC / Exit button (DR)
[5] ⇒ NO / Input control ON/OFF mode
[6] ⇒ NC / Input control ON/OFF mode
Note: The NO type of line is triggered when connected to supply minus. The NC type of line are triggered when disconnected from
supply minus. In normal condition the NC line must be shorted to ground.
[2] - IN2
INPUT FUNCTION
[2]
+ [OPTION]
[0] ⇒ Input off.
[1] ⇒ NO / Door open sensor (DC)
[2] ⇒ NC / Door open sensor (DC)
[3] ⇒ NO / Exit button (DR)
[4] ⇒ NC / Exit button (DR)
[5] ⇒ NO / Input control ON/OFF mode
[6] ⇒ NC / Input control ON/OFF mode
Note: The reader does not allow to select the same functions for more then one input. An attempt to designate the same functions for
inputs activates signalization of an error.
Note : IN3 can not be programmed. This input is permanent set to [Reporting input] type and can be used only in networked operation
mode.
[3] - S
PECIAL OPTIONS
[3]
+ [OPTION]
[0] ⇒ A, B and C options are off.
[1] ⇒ A
[2] ⇒ B
[3] ⇒ A + B
[4] ⇒ C
[5] ⇒ A + C
[6] ⇒ B + C
[7] ⇒ A + B + C
OPTION MEANING
A
[Re-programming disabled]
– This option disable entry to the Installer programming mode. This option can
only be deleted by RESET of the EEPROM memory.
B
[Access may be granted only in ON mode] –
This option disabled access for all users when controller stay in
OFF mode.
C
[Bad card timed lock-out
- Reading of card/code is blocked for 3 minutes after three consecutive attempts of
entering an unknown card or code repeated in a period shorter than 1 minute.
