Roger PR301 - User Programming Mode

PR301v2.1UK.doc 02-07-29
6
User Programming Mode
In order to enter User Programming mode do the following sequence:
• When controller stand in ON or OFF mode,
• [Enter MASTER ident.]
• [Wait until LED OPEN start blink]
• [Enter MASTER ident. again
Note: When
[Dual identification mode]
is activated operator must enter code and card (no mater what sequence) at first time but at
second time only code or card is required.
In the user programming mode, you can add/delete the NORMAL and SWITCHER identifiers. From this mode you can also go to the
Installer Programming mode for detailed setup. When in the User Programming mode the OPEN and SYSTEM LEDs are on. A
particular programming function is activated by giving its number (0,1 .. 9). After activation of the function, the OPEN and SYSTEM
LEDs starts blink which means that the controller is performing the function and wait for its completion. The following functions are
available:
[1] - A
DD
NORMAL
USER
[1]
+ [xyz] + [#] + [xyz] + [#] + [Code] + [#] + [Code] + [#] + [Card]
x y z = 100..999 ⇒ user ID number
Depending on your needs, you can skip programming the user ID , code or card.
Examples of programming:
1. [1][189][#][189][#][4562][#][4562][#][Card] programming: ID number + code + card
2. [1][#][#][4562][#][4562][#][Card] programming: code + card
3. [1][189][#][189][#][#][#][Card] programming: ID number + card
4. [1][189][#][189][#][4562][#][4562][#][#.] programming: ID number + code
5. [1][#][#][4562][#][4562][#][#] programming: code
6. [1][#][#][#][#][card] programming: card
7. [1] [card] programming: card
[2] - A
DD
SWITCHER
USER
[2]
+ [xyz] + [#] + [xyz] + [#] + [Code] + [#] + [Code] + [#] + [Card]
x y z = 001..099 ⇒ user ID number
Programming principles are as in function [1].
[3] - D
ELETE USER NO
. ...
[3]
+ [xyz]
x y z = 001..999 ⇒ user ID number
Note: The MASTER and INSTALLER identifiers can not be deleted.
[4] – M
ULTIPLY ADDING OF
NORMAL
USERS
[4]
+ [card1] + ... + [card n] + [#]
Cards should be read within 15 seconds interval. The cards will be programmed in a first found free memory space, the new cards do
not delete the users already existing in the memory.
[5] – M
ULTIPLY ADDING OF
SWITCHER
USERS
[5]
+ [card1] + ... + [card n] + [#]
Programming principles are as in function [4].
[6] – D
ELETES USER WITH ENTERED CARD OR CODE
[6]
+ [code] + [#] or
[6]
+ [card]
Note : The MASTER and INSTALLER identifiers can not be deleted.
