PR301v2.1UK.doc 02-07-29
10
[9] - P
ROGRAMMING OF
MASTER
IDENTIFIER
[9]
+ [MASTER code] + [#] + [MASTER code] + [#] + [MASTER card]
Note: The controller does not require programming of both identification forms, i.e. code and card, programming of the code or card can
be skipped (see examples as in function [8])
EEPROM RESET – Return to default (manufactures) settings
After EEPROM RESET all existing data in memory are deleted and default values are restored. After EEPROM RESET, operator must
program new MASTER identifier. The EEPROM RESET is done in the following way:
• press EEPROM RESET pushbutton until LED OPEN starts blink (approx. 6 seconds),
• release EEPROM RESET button,
• program the new MASTER identifier : [Code] + [#] + [Code] + [#] + [Card]
1. [187654][#][187654][#][Card] ;code + card
2. [187654][#][187654][#][#] ;code
3. [#][#][Card] ;card
4. [Card] ;card
• the controller is ready for operation.
Note: After the EEPROM RESET, the MASTER identifier also performs the function of the INSTALLER identifier (MASTER =
INSTALLER). You can change the INSTALLER identifier in the Installer Programming mode.
Default (manufacturing) settings of EEPROM memory
Controller identification number (ID) ;00
IN1 input ;NO / Door open sensor (DC)
IN2 input ;NO / Exit button (DR)
Reprogramming disable ;option OFF
Access may be granted only in ON mode ;option OFF
Bad card timed lock-out ;option OFF
DUAL identification mode for NORMAL users ;option OFF
DUAL identification mode for MASTER users ;option OFF
DUAL identification mode for SWITCHER users ;option OFF
Time for entry ;2 seconds
Delay before DOOR AJAR alarm ;09 seconds
Function of ALARM output ;PREALARM+DOOR AJAR+FORCED ENTRY
Technical data
Supply voltage ; 10..15Vdc
Current consumption (average) ; 70 mA
Ambient temperature ; 0..50 C deg.
Dimensions ; 105 X 106 X 31mm
Weight ; approx. 165 grams
