PR301v2.1UK.doc 02-07-29
9
[4] - U
SER IDENTIFICATION MODES
[4]
+ [OPTION]
[0] ⇒ The DUAL identification mode off.
[1] ⇒ The DUAL identification mode for NORMAL users
[2] ⇒ The DUAL identification mode for MASTER users
[3] ⇒ The DUAL identification mode for NORMAL and MASTER
[4] ⇒ The DUAL identification mode for SWITCHER
[5] ⇒ The DUAL identification mode for NORMAL and SWITCHER
[6] ⇒ The DUAL identification mode for MASTER and SWITCHER
[7] ⇒ The DUAL identification mode for NORMAL , MASTER and SWITCHER
Note: When DUAL identification mode is activated users must enter code and read card, sequence does not matter.
[5] – F
UNCTION OF THE
A
LARM OUTPUT
[5]
+ [OPTION]
[0] ⇒ The ALARM output repeats the ON/OFF condition of the controller (follows SWITCH output)
[1] ⇒ The output signalizes the condition : PREALARM
[2] ⇒ The output signalizes the condition : DOOR AJAR
[3] ⇒ The output signalizes the condition : PREALARM + DOOR AJAR
[4] ⇒ The output signalizes the condition : FORCED ENTRY
[5] ⇒ The output signalizes the condition : PREALARM + FORCED ENTRY
[6] ⇒ The output signalizes the condition : DOOR AJAR + FORCED ENTRY
[7] ⇒ The output signalizes the condition : PREALARM + DOOR AJAR + FORCED ENTRY
Note : SWITCH output can not be programmed. This output follows the controller ON/OFF mode. When controller stay in ON (green)
mode SWITCH output is activated, when controller stay in OFF (red) mode SWITCH output is deactivated.
Note: Both ALARM and SWITCH output are open collector type. The maximum voltage connected to outputs can not exceed 30V and
maximum current must be less then 150mA.
[6] - P
ROGRAMMING OF OPENING TIME AND TIME FOR CLOSING
[6]
+ [PQ] + [RS]
PQ
= 01..99 ⇒ [Time for entry]
RS = 01..99
⇒ [Delay before DOOR AJAR alarm]
Time for entry specify time interval for which door lock will be activated after access is granted. Delay before door ajar specify time
interval in which door should be closed, otherwise DOOR AJAR alarm will be activated.
Note : When controller operates with [Door open sensor] the RELAY which activates electric look will be triggered off about 2..3 second
after door became open no matter what [Time for entry] is programmed.
[7] - P
ROGRAMMING OF READER IDENTIFICATION NUMBER
[7]
+ [ID]
ID = 00..99
⇒ the reader ID number
If the controller is linked with the communication bus and operates under the PR Master software, this number identifies the controller in
networked system. All the controllers linked to the communication bus must have different ID numbers. Communication with the
controllers with the same ID numbers is not possible.
[8] - P
ROGRAMMING OF
INSTALLER
IDENTIFIER
[8]
+ [INSTALLER code] + [#] + [INSTALLER code] + [#] + [INSTALLER card]
Note: The controller does not require programming of both identification forms, i.e. code and card, programming of the code or card can
be skipped.
Examples:
1. [8][987654][#][987654][#][Card] ;(card + code)
2. [8][987654][#][987654][#][#] ;(code only)
3. [8][#][#][Card] ;(card only)
4. [8][Card] ;(card only)
