Rohde & Schwarz RTA4004 - Settings for Reference Waveforms

Waveform analysis
R&S
®
RTA4000
118User Manual 1335.7898.02 ─ 08
b) Tap "Accept Dir." .
7. If necessary, change the "File Name".
8. Optionally, add a comment.
9. Tap "Save"
10. Close the dialog box.
To load a reference waveform
1.
To open the "References" menu, tap the
menu icon and select "References".
2. Select the target "Reference" waveform.
3. Tap "Load Reference".
4. Select the "Location", the folder, and the reference file.
5. Tap "Load".
The instrument writes the waveform data to the selected reference waveform and
displays it.
7.3.2 Settings for reference waveforms
► To open the "References" menu:
a)
Tap the
menu icon in the lower right corner of the screen.
b) Scroll down. Select "References".
Reference waveforms
