Parameters:
<Format> BMP | PNG | GIF
BMP: Windows Bitmap Format
PNG: Portable Network Graphic
GIF: Graphics interchange format
*RST: PNG
Example: See Chapter 17.2.1.1, "Saving screenshots to file", on page 424
HCOPy:SIZE:X?
Returns the number of horizontal pixels of the oscilloscope screen.
Return values:
<Xsize> Numeric value
Usage: Query only
HCOPy:SIZE:Y?
Returns the number of vertical pixels of the oscilloscope screen.
Return values:
<Ysize> Numeric value
Usage: Query only
HCOPy:COLor:SCHeme <ColorScheme>
Defines the color mode for screenshots.
Parameters:
<ColorScheme> COLor | GRAYscale | INVerted
INVerted inverts the colors of the output, i.e. a dark waveform is
depicted on a white background.
*RST: COLor
Example: see Chapter 17.2.1.1, "Saving screenshots to file", on page 424
17.9.4 Instrument settings: mass MEMomory subsystem
The Mass MEMomory subsystem provides commands to access the storage media
and to save and reload instrument settings and data.
The R&S RTA4000 has the following storage devices indicated as drives:
●
/INT: internal storage with default directories for each data type
●
/USB_FRONT: USB connector on the front panel
●
/USB_REAR: USB connector on the rear panel
