Remote control commands
R&S
®
RTA4000
471User Manual 1335.7898.02 ─ 08
Parameters:
<PatternWidth> Default unit: s
TRIGger:A:PATTern:WIDTh:DELTa <PatternDelta>
Defines a range around the pattern width value specified using TRIGger:A:
PATTern:WIDTh[:WIDTh].
Parameters:
<PatternDelta> Default unit: s
17.5.7
Runt trigger
TRIGger:A:LEVel<n>:RUNT:LOWer................................................................................. 471
TRIGger:A:LEVel<n>:RUNT:UPPer..................................................................................471
TRIGger:A:RUNT:DELTa.................................................................................................471
TRIGger:A:RUNT:POLarity..............................................................................................472
TRIGger:A:RUNT:RANGe............................................................................................... 472
TRIGger:A:RUNT:WIDTh................................................................................................ 472
TRIGger:A:LEVel<n>:RUNT:LOWer <Level>
Sets the lower voltage threshold for runt detection. A positive runt crosses the lower
level twice without crossing the upper level.
Suffix:
<n>
.
1..5
Parameters:
<Level>
TRIGger:A:LEVel<n>:RUNT:UPPer <Level>
Sets the upper voltage threshold for runt detection. A negative runt crosses the upper
level twice without crossing the lower level.
Suffix:
<n>
.
1..5
Parameters:
<Level>
TRIGger:A:RUNT:DELTa <Variation>
Sets a range Δt to the reference pulse width set with TRIGger:A:RUNT:WIDTh, if
TRIGger:A:RUNT:RANGe is set to WITHin or OUTSide.
Parameters:
<Variation> Range: Depends on various settings, mainly time base and
sample rate
Trigger
