Remote control commands
R&S
®
RTM3000
473User Manual 1335.9090.02 ─ 09
Suffix:
<n>
.
1..5
Parameters:
<Level>
TRIGger:A:LEVel<n>:RISetime:UPPer <Level>
Sets the upper voltage threshold. When the signal crosses this level, the rise/fall time
measurement starts or stops depending on the selected slope.
Suffix:
<n>
.
1..5
Parameters:
<Level>
TRIGger:A:RISetime:DELTa
<Variation>
Sets a range Δt to the reference rise/fall time set with TRIGger:A:RISetime:TIME,
if TRIGger:A:RISetime:RANGe is set to Within or Outside. The instrument trig-
gers on rise/fall times inside or outside the range time ± Δt.
Parameters:
<Variation>
TRIGger:A:RISetime:RANGe <Range>
Sets how the measured rise or fall time is compared with the given limit(s).
To set the rise/fall time, use TRIGger:A:RISetime:TIME.
To set the range ± Δt, use TRIGger:A:RISetime:DELTa.
Parameters:
<Range> LONGer | SHORter | WITHin | OUTSide
LONGer
Triggers on rise/fall times longer than the given time.
SHORter
Triggers on rise/fall times shorter than the given time.
WITHin
Triggers on rise/fall times inside the range time ± Δt.
OUTSide
Triggers on rise/fall times outside the range time ± Δt.
*RST: LONG
TRIGger:A:RISetime:SLOPe <Polarity>
Sets the edge of the slope to be triggered on.
Trigger
