Rohde & Schwarz RTM3000 Series - Page 565

Remote control commands
R&S
®
RTM3000
565User Manual 1335.9090.02 ─ 09
17.8.8.2 Bode plot diagram settings
BPLot:GAIN:DATA?........................................................................................................565
BPLot:GAIN:ENABle...................................................................................................... 565
BPLot:GAIN:POSition.....................................................................................................565
BPLot:GAIN:SCALe....................................................................................................... 565
BPLot:PHASe:DATA?..................................................................................................... 566
BPLot:PHASe:ENABle?..................................................................................................566
BPLot:PHASe:POSition?................................................................................................ 566
BPLot:PHASe:SCALe?...................................................................................................566
BPLot:AMPLitude:ENABle.............................................................................................. 566
BPLot:AMPLitude:POSition.............................................................................................566
BPLot:AMPLitude:SCALe................................................................................................567
BPLot:GAIN:DATA?
Returns the data of the gain waveform.
Parameters:
<GainData>
Usage: Query only
BPLot:GAIN:ENABle
Enables the gain waveform for the Bode plot.
Parameters:
<Enable> ON | OFF
*RST: ON
BPLot:GAIN:POSition
Sets the vertical position of the gain waveform in divisions.
Parameters:
<WaveformPosition> Range: -20.0 to 20.0
Increment: 0.1
*RST: 3.0
BPLot:GAIN:SCALe
Sets the vertical scale for the gain waveform.
Parameters:
<WaveformScale> Range: 0.1 to 20.0
Increment: 0.1
*RST: 20.0
Applications
