SUPER ELF S3 – Dornier
15
Winding sensor
Sets the sensitivity of the photocell which is controlling the outgoing coils.
• Possible setting: normal yarn / fine yarn
• Recommended setting: normal yarn
Reserve sensor
Sets the sensitivity of the photocell which is controlling Automatic Reserve Position.
• Possible setting: normal yarn / fine yarn
• Recommended setting: normal yarn
Length correction
Avoids wrong weft length measurement due to the eventual overlapping of the coils on
the Spool body.
• Possible setting: ON / OFF
• Recommended setting: ON
Note: Set OFF in case of short picks (one coil less) with irregular insertion times.
Double yarn sensor
Controls the yarn break by means of an external sensor (Roj PIEZO sensor TFE6). This is
normally used in case of multiple weft insertions, i.e. when there is more than one yarn used
with one feeder.
• Possible setting: ON / OFF
Rotation direction
To set the winding direction of the Feeder according to the yarn twist.
• Possible setting: Z / S
Note: When changing the winding direction, the coils pitch has to be changed too.
