SUPER ELF S3 – Dornier
Back panel control elements
1 CONNECTION OF AIR LINE INPUT
2 CONNECTION OF AIR LINE FOR FULL AIR THREADING
Full air threading is possible only in combination with Funnel. If the feeder is fitted with eyelet
holder, or without any balloon control, this connection must be closed with relevant plug that it
is supplied with the feeder.
3 HALF THREADING BUTTON
Insert the yarn into the eyelet and press the half threading button (3), whilst lightly holding the
yarn.
4 FULL THREADING BUTTON
Insert the yarn into the eyelet and press the full threading button (4), whilst lightly holding the
yarn.
