Page #2 background image
2
Oct.2004(Jul.2006) CB-100
CAUTIONARY NOTES
PARTS LIST
Due to one or more of the following reasons, parts with parts code ********
cannot be supplied as service parts.
Part supplied only as a component in a complete assembly
Copyright does not permit the part to be supplied
Part is sold commercially
SPECIFICATIONS
Rated Power Output
100 W
Nominal Input Level (1kHz)
INPUT: -10 dBu/1M OHM
* 0 dBu = 0.775 Vrms
Speaker
30 cm (12 inches) + Tweeter (Coaxial, 2-way)
Controls
POWER Switch
<INPUT>
PAD Switch
<COMPRESSION>
COMPRESSION Knob
<COSM AMPLIFIER>
SHAPE Switch, TYPE Knob (SUPER FLAT, FLIP TOP, B MAN, T.E, BASS 360,
SESSION, CONCERT 810, OCTAVE BASS), GAIN Knob, VOLUME Knob
<EQUALIZER>
BASS Knob, LOW-MID Knob, HIGH-MID Knob, TREBLE Knob
<EFX>
EFX Knob (CHORUS, FLANGER, T-WAH)
<DELAY/REVERB>
DELAY/REVERB Knob
<BALANCED OUT>
SELECT Switch (DI OUT/LINE OUT),GND LIFT Switch (ON/OFF)
Indicators
Power, PEAK, COMPRESSION, SHAPE, EFX, DELAY/REVERB
Connectors
INPUT Jack (1/4” phone type)
RECORDING OUT/PHONES Jack (Stereo 1/4” phone type)
FOOT SW Jack (EFX, DELAY/REVERB) (1/4” phone type)
EXT SPEAKER Jack (1/4” phone type)
LINE OUT Jack (1/4” phone type)
TUNER OUT Jack (1/4” phone type)
BALANCED OUT Jack (XLR type)
Power Supply
AC 117 V, AC 230 V or AC 240 V
Power Consumption
28 W
Dimension
407 (W) x 310 (D) x 469 (H) mm
16-1/16 (W) x 12-1/4 (D) x 18-1/2 (H) inches
Weights
17 kg / 37 lbs 8 oz
Accessories
Owner’s Manual ENGLISH(#SD000521),
JAPANESE(#SD000520)
Option
Foot switch FS-5U (BOSS)
* In the interest of product improvement, the specifications and/or appearance of
this unit are subject to change without prior notice.
