8
Oct.2004(Jul.2006) CB-100
PARTS LIST
fig.part1e
on P=PANEL PCB, on M=MAIN BOARD.
SAFETY PRECAUTIONS:
The parts marked have
safety-related characteristics. Use
only listed parts for replacement.
NOTE: The parts marked # are new. (initial parts)
Due to one or more of the following reasons,
parts with parts code ******** cannot be supplied as service parts.
• Part supplied only as a component in a complete assembly
• Copyright does not permit the part to be supplied
• Part is sold commercially
The description "Q'TY" means a necessary number of the parts per one product.
CASING
# SD000160 CABINET ASSY 1
NOTE: Spare parts for CABINET ASSY includes the following parts.
# SD000162 CORNER PROTECTOR 4
SD000463 HANDLE HOLDER 2
SD000462 HANDLE PLATE 1
SD000461 HANDLE RUBBER 1
SD000078 RUBBER FOOT 23X15T(75) 4
SD000066 TRIM 1
# SD000167 GRILL ASSY 1
NOTE: Spare parts for GRILL ASSY includes the following parts.
SD000231 BASS BADGE W/HOT STAMP 1
SD000017 BADGE LOGO (Roland) 1
CHASSIS
# SD000161 CHASSIS 1
22360705 CORD HOOK 2
# SD000182 STAY 3
KNOB,BUTTON
SD000043 R-KNOB 10
SD000082 PUSH BUTTON 2
SWITCH
03567001 SLIDE SWITCH SSAB110100 SSW1,SSW2 on M 2
SD000488 ROTARY SWITCH SR1712-0108-15F0A-N9-N RSW on P 1
# 03782367 SEESAW SWITCH JW-L11RKK POWER SWITCH 1
SD000099 PUSH SWITCH ESB64619 PSW1,PSW2 on P 2
JACK,EXT TERMINAL
00122123 XLR CONNECTER YKF52-5003 JK3 on M 1
13449146 6.5MM JACK YKB21-5012 (W/SW) JK1 on M 1
13449145 6.5MM JACK YKB21-5010 JK4,JK5,JK7,JK8 on M 4
13449252 6.5MM JACK YKB21-5006 (STEREO W/SW) JK2 on M 1
# SD000175 JACK S2 BBB PC-C KINKED JK10 on M 1
SPEAKER,BUZZER
# SD000181 SPEAKER 12INCH (8OHM) SPK-BG413 1
PWB ASSY
# SD000519 PANEL PCB ASSY 1
# SD000514 MAIN PCB ASSY 1
NOTE: Spare parts for MAIN PCB ASSY includes the following parts.
******** PS-1 BOARD 1
******** IN BOARD 1
******** AMP BOARD 1
******** PHO BOARD 1
IC
03890123 UPD780034AGK-B23-9ET IC (CPU) IC1 on M 1
SD000493 NJM78M12DLA IC (V RGL) IC15 on M 1
SD000494 NJM79M12DLA IC (V RGL) IC16 on M 1
03015923 S-80130ANMC IC (RESET) IC3 on M 1
03015912 REGULATOR UPC2905T-T2 IC (REGULATOR) IC9 on M 1
01678512 UPC2933T-T2 IC (REGULATOR) IC9 on M 1
# SD000183 TA2022 IC (POWER AMP) IC203 on M 1
