Roland CUBE-100 BASS Service Notes

5
Oct.2004(Jul.2006) CB-100
EXPLODED VIEW PARTS LIST
(CABINET)
[Parts]
[Screws]
No PART CODE PART NAME DESCRIPTION Q’TY
1 SD000160 CABINET ASSY 1
2 SD000181 SPEAKER 12INCH (8OHM) SPK-BG413 1
3 SD000066 TRIM SASH 1
4 SD000162 CORNER PROTECTOR 4
5 SD000167 GRILL ASSY 1
6 SD000463 SD000461 HANDLE RUBBER 1
7 SD000462 HANDLE PLATE 1
8 SD000461 SD000463 HANDLE HOLDER 2
9 SD000017 BADGE LOGO (Roland) 1
10 SD000464 HIMERON W/ADH 6 X 50 X 0.5T 3
11 SD000078 RUBBER FOOT 23X15T(75) 4
12 SD000231 BASS BADGE W/HOT STAMP 1
13 SD000265 RUBBER SPONGE BUSH 12X20H CUT 1
14 SD000169 HIMERON W/ADH 10 X 115 X 0.25T 2
No PART CODE PART NAME DESCRIPTION Q’TY
a 40010701 SCREW 4X35 TRUSS TAPTITE A1 BZC 4
b SD000432 SCREW 3X16 TRUSS TAPTITE A1 BZC 29
c 40010145 SCREW M4X25 ORIGINAL TRASS MACHINE SCREW BZC 12
40010545 TRUSS HEAD SPECIAL FE BZC
d SD000019 SCREW M4X25 BINDING MACHINE SCREW BZC 8
e SD000048 SCREW M5X35 OVALHEAD MACHINE BZC 4
f 40230778 SCREW M3X8 OVALHEAD MACHINE BZC 2
g 40011689 SPEED NUT M3 FSN-3001 2
h SD000370 PLATE WASHER 4.2 X 10 X 0.5T 4
i SD000430 RESIN WASHER 11 X 4.1 X 1T 4
j SD000068 SCREW 4X25 TRUSS TAPTITE A1 BZC 4
