4
Oct.2004(Jul.2006) CB-100
EXPLODED VIEW (CABINET)
fig.CB100-cabinet-e.eps
+
-
FRONT VIEW
W7(RED)
W8(BLACK)
HIMERON 10x115xt0.25 W/ADH
TRIM SASH
Refer to "EXPLODED VIEW
(CHASSIS)".
Remove the
5 , 2 , 13 before
removing the CHASSIS. Once
you remove
13 , you can't use
it any more. When you remove
the CHASSIS, order
13 for
service.
BOTTOM VIEW
The speaker terminals face the down side.
THE ANGLE OF SPEAKER UNIT
THE CONNECTION OF SPEAKER TERMINAL
ATTACHING OF HIMERON
10x115xt0.25 W/ADH on TRIM SASH
BADGE BACK SIDE
b
b
h
j
c
b
b
b
e
b
c
1
d
2
3
4
7
6
11
i
a
f
g
10
5
9
12
4
13
14
14
c
8
