10
CUBE-ST/CUBE-ST-RSep. 2007
Parts List
fig.part1e
SAFETY PRECAUTIONS:
The parts marked have
safety-related characteristics. Use
only listed parts for replacement.
NOTE: The parts marked # are new. (initial parts)
Due to one or more of the following reasons,
parts with parts code ******** cannot be supplied as service parts.
• Part supplied only as a component in a complete assembly
• Copyright does not permit the part to be supplied
• Part is sold commercially
The description "Q'TY" means a necessary number of the parts per one product.
CASING
# SD001023 CORNER PROTECTOR TOP 2
# SD001027 RUBBER FOOT D30.5XT10.5 4
# SD001025 CORNER PROTECTOR BOTTOM R 1
# SD001024 CORNER PROTECTOR BOTTOM L 1
SD000017 BADGE 1
# SD001033 BATTERY COVER ASSY 1
# SD001030 CABINET ASSY BLACK (for CUBE-ST) 1
# SD001031 CABINET ASSY RED (for CUBE-ST-R) 1
# SD001022 CHASSIS ASSY 1
22365714 CORD HOOK 1
# SD001028 GRILL SILVER (for CUBE-ST) 1
# SD001029 GRILL BRIGHT SILVER (for CUBE-ST-R) 1
SD000035 HANDLE WITH ESCUTHEON 1
# SD001026 TRIM SASH 1
KNOB, BUTTON
SD000043 R-KNOB W/HOT STAMP 11
SD000906 KEYTOP 1
SD000082 PUSH BUTTON 1
SWITCH
SD000907 ROTARY SWITCH SR1712F-0108-175F0A-N9-N-008 SW1 on Panel Board 1
01348745 SWITCH (PUSH) SPUP192700LF SW1 on MIC Board 1
02897801 SEESAW SWITCH SDDJE13200 94V-0 1
JACK, EXT TERMINAL
13449146 6.5MM JACK YKB21-5012 (W/SW) JK3 on Input Board 1
13449252 6.5MM JACK YKB21-5006 (STEREO W/SW) JK1 on Main Board, JK4, JK5 on Pedal Board 3
02456390 3.5MM JACK STEREO YKB21-5290 JK2 on Main Board 1
01901001 XLR CONNECTER NCJ9FI-H JK4 on MIC Board 1
13449717 ADAPTOR JACK HEC2392-0101509 JK6 on Jack Board 1
SPEAKER, BUZZER
# SD001032 SPEAKER W6504-436A 2
PWB ASSY
# SD000993 MAIN BOARD ASSY 1
# SD000995 PANEL BOARD ASSY 1
DIODE
# SD001038 LED (GREEN) L-710XVGD-E-SZ LED3 on Panel Board 1
# SD001037 LED (RED) L-710XSURD-E-SZ LED1, LED2, LED4, LED5 on Panel BORD 4
POTENTIOMETER
# SD001036 POTENTIOMETER RV110F-20E1-15A-B100K-0061 VR1 on MIC Board 1
SD000911 POTENTIOMETER RD901F-40E1-15F-0B10K-
00DM8
VR1-VR10 on Panel Board 10
FUSE, FUSE HOLDER
# SD001039 FUSE MRT160/250V F2 on Main Board 1
F2559306R0 FUSE MRT 1.6A/250V F1 on Jack Board 1
WIRING, CABLE
# SD001035 BATTERY WIRING 1
To Next Page
