5
Sep. 2007 CUBE-ST/CUBE-ST-R
Location of Controls Parts List
No. Part Code Part Name Description Q’ty
1 SD000911 POTENTIOMETER RD901F-40E1-15F-0B10K-00DM8 10
SD000043 R-KNOB W/HOT STAMP 10
17048630 VR ACCESSORY NUT M9 10
40452178 VR WASHER M9 10
2 SD001038 LED GREEN L-710XVGD-E-SZ 1
3 SD001037 LED RED L-710XSURD-E-SZ 3
4 02456390 3.5MM JACK STEREO YKB21-5290 1
5 13449252 6.5MM JACK YKB21-5006 (STEREO W/SW) 1
22150756 JACK NUT 2 PLASTIC/BLK 1
6 01901001 XLR CONNECTER NCJ9FI-H 1
40011101 SCREW 3X8 BINDING TAPTITE B BZC 2
7 SD000082 PUSH BUTTON 1
01348745 SWITCH (PUSH) SPUP192700LF 1
8 SD000043 R-KNOB W/HOT STAMP 1
SD001036 POTENTIOMETER RV110F-20E1-15A-B100K-0061 1
17048630 VR ACCESSORY NUT M9 1
40452178 VR WASHER M9 1
9 13449146 6.5MM JACK YKB21-5012 (W/SW) 1
22150756 JACK NUT 2 PLASTIC/BLK 1
10 SD000906 KEY TOP 2
SD001037 LED RED L-710XSURD-E-SZ 1
11 SD000907 ROTARY SWITCH SR1712F-0108-175F0A-N9-N-008 1
SD000043 R-KNOB W/HOT STAMP 1
17048630 VR ACCESSORY NUT M9 1
40452178 VR WASHER M9 1
12 02897801 SEESAW SWITCH SDDJE13200 94V-0 1
13 40454856 SCREW M4X10 BINDING NI 1
14 13449717 ADAPTOR JACK HEC2392-0101509 1
15 40237101 SCREW M3X8 PAN MACHINE W/SW+SMALL PW BZC 1
16 13449252 6.5MM JACK YKB21-5006 (STEREO W/SW) 2
22150756 JACK NUT 2 PLASTIC/BLK 1
17 22365714 CORD HOOK 1
40237101 SCREW M3X8 PAN MACHINE W/SW+SMALL PW BZC 1
18 SD001033 BATTERY COVER ASSY 1
To Next Page
