CUBE-ST/CUBE-ST-RSep. 2007
Exploded View Parts List
Parts
No. Part Code Part Name Description Q’ty
1 SD000017 BADGE 1
2 SD001028 GRILL SILVER (for CUBE-ST) 1
SD001029 GRILL BRIGHT SILVER (for CUBE-ST-R) 1
3 SD001030 CABINET ASSY BLACK (for CUBE-ST) 1
SD001031 CABINET ASSY RED (for CUBE-ST-R) 1
* The CABINET ASSY includes the following parts.
4 SD001026 TRIM SASH 1
5 SD001023 CORNER PROTECTOR TOP 2
6 SD001024 CORNER PROTECTOR BOTTOM L 1
7 SD001025 CORNER PROTECTOR BOTTOM R 1
8 SD001027 RUBBER FOOT D30.5XT10.5 4
9 SD001032 SPEAKER W6504-436A 2
10 SD001022 CHASSIS ASSY 1
* The CHASSIS ASSY includes the following parts.
******** EVA PACKING 370x40x1t W/ADH 1
******** EVA PACKING 100x20x1t W/ADH 2
******** EVA PACKING 120x10x1t W/ADH 4
******** EVA PACKING 19x15x0.5t W/ADH 4
11 SD000035 HANDLE WITH ESCUTCHEON 1
12 SD000043 R-KNOB W/HOT STAMP 12
13 SD000993 MAIN BOARD ASSY 1
* The MAIN BOARD ASSY includes the following parts.
14 ******** JACK BOARD ASSY 1
15 ******** MIC BOARD ASSY 1
16 ******** INPUT BOARD ASSY 1
17 SD000995 PANEL BOARD ASSY 1
* The PANEL BOARD ASSY includes the following parts.
18 ******** PEDAL BOARD ASSY 1
19 22365714 CORD HOOK 1
20 SD000082 PUSH BUTON BLACK 1
21 SD000906 KEYTOP ROUND,WHITE 1
22 22150756 JACK NUT 2 PLASTIC/BLK 4
23 02897801 SEESAW SWITCH SDDJE13200 94V-0 1
24 SD000422 BATTERY SHEET 1
25 SD001033 BATTERY COVER ASSY 1
* The BATTERY COVER ASSY includes the following parts.
******** EVA PACKING 28x2x0.5t W/ADH 2
******** BATTERY CUSHION 1
26 SD000421 BATTERY PLATE 1
27 SD000418 BATTERY CASE 1
28 SD000427 BATTERY SPRING +- 1
29 SD000426 BATTERY SPRING + 1
30 SD000425 BATTERY SPRING - 1
31 SD001035 BATTERY WIRING 1
32 SD000464 HIMERON W/ADH 6 x 50 x t0.5 3
33 SD000446 HIMERON W/ADH 4x15xt0.25 2
34 SD001047 DC JACK HOLDER 1
