3
Sep. 2007 CUBE-ST/CUBE-ST-R
Specifications
CUBE-ST, CUBE-ST-R
Rated Power Output
STEREO 5 W (2.5 W + 2.5 W)
Nominal Input Level (1 kHz)
MIC/LINE Channel: -50/-10 dBu
GUITAR/INSTRUMENT Channel: -10 dBu
STEREO AUX IN: -10 dBu
* 0 dBu = 0.775 V rms
Speakers
16 cm (6.5 inches) x 2
Controls
POWER Switch
<MIC/LINE Channel>
SELECT Switch (MIC/LINE)
VOLUME Knob
EQUALIZER Knobs (BASS, TREBLE)
DELAY/REVERB Knob
<GUITAR/INSTRUMENT Channel>
TUNER Switch
TYPE Switch
GAIN Knob
VOLUME Knob
EQUALIZER Knobs (BASS, MIDDLE, TREBLE)
EFX Knob
DELAY/REVERB Knob
Indicators
TUNER
POWER
Connectors
<MIC/LINE Channel>
Input Jacks (XLR type, 1/4-inch phone type)
Foot Switch Jack (1/4-inch TRS phone type, TIR: mute, RING: DELAY/
REVERB)
<GUITAR/INSTRUMENT Channel>
Input Jack (1/4-inch phone type)
Foot Switch Jack (1/4-inch TRS phone type, TIR: EFX, RING: DELAY/
REVERB)
AUX IN Jack (Stereo miniature phone type)
PHONES Jack (Stereo 1/4-inch phone type)
AC Adaptor Jack
Power Supply
DC 9 V: AC Adaptor or Dry Battery (LR6 (AA) type) (optional) x 6
Current Draw
235 mA
Dimensions
415 (W) x 295 (D) x 250 (H) mm
16-3/8 (W) x 11-5/8 (D) x 9-7/8 (H) inches
Weight
5.2 kg (including Battery)
11 lbs 8 oz (including Battery)
Accessories
AC Cord for 117V (#01903345)
for 230V (#01903356)
for 240V (#03785590)
AC Adaptor (#04236101)
Owner’s Manual English (#SD001041)
Options
Carrying Case: CB-CS1
Foot Switch: FS-5U (BOSS), FS-6(BOSS)
Connection Cable: PCS-31
* In the interest of product improvement, the specifications and/or appearance of
this unit are subject to change without prior notice.
Difference between CUBE-ST and CUBE-ST-R
CUBE-ST-R is different from CUBE-ST in the following parts. Other specifications are all same.
CUBE-ST CUBE-ST-R
Part Code Part Name Description Part Code Part Name Description
SD001030 CABINET ASSY Black SD001031 CABINET ASSY Red
SD001028 GRILL Silver SD001029 GRILL Bright Silver
SD001042 PACKING CASE SD001043 PACKING CASE
To Next Page
