Roland Fantom G8

179
Effects List
Overview Sound 1 Sound 2 Sound 3 Pad Sampler
Menu/System
AppendixSequencer
61: PITCH SHIFTER
(Feedback Pitch Shifter)
A stereo pitch shifter.
fig.MFX-61
62: 2VOICE PITCH SHIFTER
Shifts the pitch of the original sound. This 2-voice pitch shifter has
two pitch shifters, and can add two pitch shifted sounds to the
original sound.
fig.MFX-62
63: STEP PITCH SHIFTER
A pitch shifter in which the amount of pitch shift is varied by a 16-
step sequence.
fig.MFX-63
64: OVERDRIVE → CHORUS
fig.MFX-66
Parameter
Value Description
Coarse #1 -24– +12 semi Adjusts the pitch of the pitch
shifted sound in semitone steps.
Fine #1 -100– +100 cent Adjusts the pitch of the pitch
shifted sound in 2-cent steps.
Delay Time 0–1300 ms, note Adjusts the delay time from the
direct sound until the pitch shift-
ed sound is heard.
Feedback # -98– +98 % Adjusts the proportion of the
pitch shifted sound that is fed
back into the effect. Negative (-)
settings will invert the phase.
Low Gain -15– +15 dB Gain of the low range
High Gain -15– +15 dB Gain of the high range
Balance # D100:0W–
D0:100W
Volume balance between the di-
rect sound (D) and the pitch
shifted sound (W)
Level 0–127 Output Level
Parameter
Value Description
Pitch 1:
Coarse #1
-24-+12 semi Adjusts the pitch of Pitch Shift 1
in semitone steps.
Pitch 1:Fine #1 -100-+100 cent Adjusts the pitch of Pitch Shift
Pitch 1 in 2-cent steps.
Pitch 1:Delay 0–1300 ms, note Adjusts the delay time from the
direct sound until the Pitch Shift
1 sound is heard.
Pitch 1:Feed-
back #
-98– +98 % Adjusts the proportion of the
pitch shifted sound that is fed
back into the effect. Negative (-)
settings will invert the phase.
Pitch 1:Pan # L64-63R Stereo location of the Pitch Shift 1
sound
Pitch 1:Level 0–127 Volume of the Pitch Shift1 sound
Pitch 2:
Coarse #2
-24-+12 semi Settings of the Pitch Shift 2
sound.
The parameters are the same as
for the Pitch Shift 1 sound.
Pitch 2:Fine #2 -100-+100 cent
Pitch 2:Delay 0–1300 ms, note
Pitch 2:Feed-
back #
-98– +98 %
Pitch 2:Pan # L64-63R
Pitch 2:Level 0–127
Low Gain -15– +15 dB Gain of the low range
L in
R in
Pitch Shifter
Pitch Shifter
L out
R out
2-Band EQ
2-Band EQ
L in
R in
L out
R out
2Voice Pitch Shifter
Level 1
Balance W
Balance D
Balance W
Balance D
Level 1
Pan 2 R
Pan 1 L
Pan 1 R
Pan 2 L
High Gain
-15– +15 dB Gain of the high range
Level Balance A100:0B-A0:100B Volume balance between the
Pitch Shift 1 and Pitch Shift 2
sounds
Balance D100:0W-D0:100W Volume balance between the di-
rect sound (D) and the pitch
shifted sound (W)
Level 0-127 Output Level
Parameter
Range Explanation
Step 01–16
-24– +12 semi Amount of pitch shift at each
step (semitone units)
Rate # 0.05–10.00 Hz, note Rate at which the 16-step se-
quence will cycle
Attack # 0–127 Speed at which the amount of
pitch shift changes between
steps
Gate Time # 0–127 Duration of the pitch shifted
sound at each step
Fine -100– +100 cent Pitch shift adjustment for all
steps (2-cent units)
Delay Time 0–1300 ms, note Delay time from the original
sound until the pitch-shifted
sound is heard
Feedback # -98– +98% Proportion of the pitch-shift-
ed sound that is to be returned
to the input (negative values
invert the phase)
Low Gain -15– +15 dB Amount of boost/cut for the
low-frequency range
High Gain -15– +15 dB Amount of boost/cut for the
high-frequency range
Balance # D100:0W–D0:100W Volume balance of the origi-
nal sound (D) and pitch-shift-
ed sound (W)
Level 0–127 Output volume
Parameter
Value Description
Overdrive
Drive #
0–127 Degree of distortion
Also changes the volume.
Overdrive
Pan #
L64–63R Stereo location of the overdrive
sound
Chorus Pre
Delay
0.0–100.0 ms Adjusts the delay time from the
direct sound until the chorus
sound is heard.
Chorus Rate # 0.05–10.00 Hz, note Frequency of modulation
Chorus Depth 0–127 Depth of modulation
Parameter
Value Description
L in
R in
Step Pitch Shifter
Step Pitch Shifter
L out
R out
2-Band
EQ
2-Band
EQ
L in
R in
Chorus
Overdrive
L out
R out
Balance W
Balance W
Balance D
Balance D
