Roland FP-10-BK

20
FP-10-BK/BKL, KSCFP10-BKFeb. 2019
Parts List (FP-10-BK/BKL)
fig.-part1-e.eps
Note: The parts marked # are new. (initial parts) The description “Q’ty” means a necessary number of the parts per one product.
Due to one or more of the following reasons, parts with parts code ******** cannot be supplied
as service parts.
• Supply is prohibited due to copyright restrictions.
• It is carried in electronic data on the Roland web site.
• The part is made to order (at current market price).
• It can be replaced with an article on the market. (battery or etc.)
• It is a package or an accessory irrelevant to the function maintenance of the main body.
• A number of circuit boards are grouped together and supplied as a single circuit board (under a different part code).
• Reissuance is restricted.
• It is supplied as an assembled part
(under a different part code).
Safety Precautions:
The parts marked have
safety-related characteristics. Use
only listed parts for replacement.
CASING
# 5100061705 TOP CASE 1
# 5100061720 BOTTOM CASE 1
CHASSIS
# 5100063190 CENTER HOLDER 2
# 5100061708 MAIN BOARD HOLDER 1
5100047922 SCREW HOLDER 4
KNOB, BUTTON
5100047917 KEYTOP MX4H CLR 1
SWITCH
01458501 TACT SWITCH SKQMATE010 4
JACK, EXT TERMINAL
04452945 3.5MM JACK YKB21-5344N 1
13449275 6.5MM JACK YKB21-5074 1
02900312 DC JACK HEC0470-01-640 1
04459190 USB CONNECTOR A TYPE FEMALE YKF45-0033N 1
5100009531 USB CONNECTOR B TYPE FEMALE YKF45-0044N 1
SPEAKER, BUZZER
# 5100061729 SPEAKER FR-5IN-06-CF15C 2
KEYBOARD ASSY
# 5100066077 KEYBOARD ASSY PX-7D SV SERVICE ASSY 1
PWB ASSY
# 5100055261 MAIN BOARD ASSY 1
# 5100061168 JACK BOARD ASSY 1
# 5100061169 PANEL BOARD ASSY 1
WIRING, CABLE
# 5100061629 WIRING 1061#28 5X390-PHR-PHR-F 1
5100047148 WIRING 1061#28 7X280-PHR-PHR-F 1
# 5100061631 WIRING 1061#28 8X280-PHR-PHR-F 1
5100056949 WIRING 1061#28 10X280-PHR-PHR-F 1
5100056950 WIRING 1061#28 11X550-PHR-PHR-F 1
# 5100061625 WIRING W01 (SPL) 1
# 5100061626 WIRING W02 (SPR) 1
SCREWS
40459534 SCREW M3X10 PAN MACHINE W/SW+PW(5.8MM) BZC 3
40011056 SCREW 3X6 BINDING TAPTITE B ZC 1
40011312 SCREW 3X8 BINDING TAPTITE P FE BZC 15
40012345 SCREW 4X10 BINDING TAPTITE B BZC 29
# 5100065041 SCREW 4X10 BINDING TAPTITE P ZC 30
5100047746 SCREW 4X14 BINDING TAPTITE P BZC 8
