21
FP-10-BK/BKL, KSCFP10-BKFeb. 2019
Parts List (KSCFP10-BK)
fig.-part1-e.eps
MISCELLANEOUS
# 5100061709 LED INDICATOR 1
5100049094 FOOT SJ-5012 BLK 5
# 5100061707 KEY FELT 1
# 5100061989 ABSORPTIVE FELT 50X25 1
# 5100061992 ABSORPTIVE FELT 245X25 3
# 5100061991 ABSORPTIVE FELT 360X25 1
# 5100061990 ABSORPTIVE FELT 450X25 1
# 5100061988 ABSORPTIVE FELT 730X25 1
5100049095 CUSHION A 2
# 5100063476 REAR CUSHION 2
# 5100063477 SIDE CUSHION 2
# 5100061710 TACT SW CUSHION 1
40017378 COATING CLIP CS-7 2
40016545 LOCKING TOOL FOR INSULOK TIE SKM-1 1
40016523 INSULOK TIE 100M/M T-18R (1000 PCS ORDERING PER) 3
40232123 ACETATE TAPE NITTO #5 BLACK W20MM 30M 20P -
40122556 DOUBLE FACED ADHESIVE TAPE #575X W30MM 30M -
5100021076 DOUBLE SIDED ADHESIVE TAPE NITTO #5000NS W5MM -
17049543 GREASE FOR KEY FLOIL G-336A WHITE (93 GRAM) -
17041858 GREASE FOR KEY MOLYKOTE G-1039 (50 GRAM) -
ACCESSORIES (Standard)
# 5100061706 MUSIC REST 1
# 5100061927 AC ADAPTOR WITHOUT AC CORD PSB-5U 1
5100048283 AC CORD SET 100V EYEGLASS ARK-VFF 1.0M (19) for 100V 1
02562456 AC CORD SET 120V 1.0M (NON POLAR) (22, 28) for 117VU, 117VU/CS 1
5100012293 AC CORD SET 117VBL 1.0M FOR PSB (26) for 117VBL 1
5100018086 AC CORD SET 230VE 1.0M FOR EPS (38) for 230VE/EU 1
01903356 AC CORD SET 230V 1.0M FOR PSB (38) for 230VE/EU 1
5100033404 AC CORD SET 240V SP501-IS037 PSB 1.0M (59) for 240VA 1
5100019558 AC CORD SET 220V CCC SP505A-IS037 1.0M (65) for 220VCN 1
5100039367 AC CORD SP021A+IS037 220VK 2.5M 2P (66) for 220VK 1
# 5100061924 OWNER’S MANUAL MULTILANGUAGE 1
Note: The parts marked # are new. (initial parts) The description “Q’ty” means a necessary number of the parts per one product.
Due to one or more of the following reasons, parts with parts code ******** cannot be supplied
as service parts.
• Supply is prohibited due to copyright restrictions.
• It is carried in electronic data on the Roland web site.
• The part is made to order (at current market price).
• It can be replaced with an article on the market. (battery or etc.)
• It is a package or an accessory irrelevant to the function maintenance of the main body.
• A number of circuit boards are grouped together and supplied as a single circuit board (under a different part code).
• Reissuance is restricted.
• It is supplied as an assembled part
(under a different part code).
Safety Precautions:
The parts marked have
safety-related characteristics. Use
only listed parts for replacement.
CASING
# 5100061723 CENTER BOARD 1
# 5100061721 SIDE BOARD L 1
# 5100061722 SIDE BOARD R 1
# 5100063645 TOE BLOCK 2
# 5100063800 TOE BLOCK 2
CHASIS
5100047929 ANGLE 4
5100046679 CENTER BOARD HOLDER 2
SCREWS
40238145 SCREW M5X12 TRUSS MACHINE BZC 6
40679101 SCREW M5X20 TRUSS MACHINE FE BZC 4
40675701 SCREW 3.5X16 BINDING TAPPING A FE BZC 4
40012145 SCREW 4X14 TRUSS TAPPING A FE BZC 30
MISCELLANEOUS
5100047118 FOOT 4
To Next Page
