Roland FP-10-BK User Manual

24
FP-10-BK/BKL, KSCFP10-BKFeb. 2019
1. LED Test
This item tests the operation of each LED.
1. Verify that Vol 1–5 light up and FUNCTION flashes.
2. Press FUNCTION to advance to the next test item.
2. Verifying the Version
This item verifies the various versions and whether the Bluetooth
function is enable or not.
When the unit enters this test item, Vol 1 flashes momentarily and the
unit says “ichi” in Japanese.
1. Press Vol + several times to verify that the unit says in the sequence
shown below.
“ichi”
→ “ni”→ “san” → “bow-wow” → “mew-mew” → “ding”
2. Press Vol - several times to verify that the unit says in the reverse of the
sequence shown above.
3. Press Vol + or Vol - to let the unit say “ichi.”
At this time, each LED lights up or goes dark to display the Program
version as shown in the tables below.
o: lights up, -: goes off
(Example) for ver. 1.01
Vol 5: Lights out
Vol 4: Lights up
Vol 3: Lights out
Vol 2: Lights out
Vol 1: Lights out
FUNCTION:Lights up
4. Press Vol + or Vol - to let the unit say “ni.”
At this time, each LED lights up or goes dark to display the Loader
version as shown in the tables of step 3.
5. Press Vol + or Vol - to let the unit say “san.”
At this time, each LED lights up or goes dark to display the Keyboard
CPU version as shown in the tables of step 3.
6. Press Vol + or Vol - to let the unit say “bow-wow.”
At this time, each LED lights up or goes dark to display the Bluetooth LE
version as shown in the tables of step 3.
7. Press Vol + or Vol - to let the unit say “mew-mew.”
At this time, Vol 1 or Vol 2 lights up to indicate whether the Bluetooth
function is enable or not.
Vol 1 Lights up: Bluetooth function is enable.
Vol 2 Lights up: Bluetooth function is not enable.
8. Press FUNCTION to advance to the next test item.
3. Bluetooth Function Setting
This item sets the unit to have or not have the Bluetooth function.
When the unit enters this test item, Vol 2 flashes momentarily.
Vol 1 and Vol 2 flash.
1. To set that Bluetooth function is enable (FP-10-BK), press Vol +. To set
that Bluetooth function is not enable (FP-10-BKL), press Vol -.
FUNCTION flashes.
* For the correct model name, refer to the model name sticker affixed to the center
back on the bottom of the unit.
2. Press FUNCTION to advance to the next test item.
4. BLE Test
When the unit enters this test item, Vol 1 and Vol 2 flash momentarily.
This test is not executed in servicing. Press FUNCTION to advance to the
next test item.
5. Switches and LEDs Test
This item tests the operation of the switches and LEDs.
When the unit enters this test item, Vol 3 flashes momentarily.
Vol 1 flashes.
1. Press Vol + and verify that the LEDs flash in the sequence shown below
with each press.
Vol 1
→ Vol 2 → Vol 3 → Vol 4 → Vol 5
* Pressing Vol + produces the piano sound.
2. When Vol 5 is flashing, press Vol -.
FUNCTION flashes.
3. Press FUNCTION to advance to the next test item.
Integer Portion of the
Version Number
Vol 5 Vol 4
0 - -
1 - o
2 o -
3 o o
Decimal Portion of
the Version Number
Vol 3 Vol 2 Vol 1 FUNCTION
00 - - - -
01 - - - o
02 - - o -
03 - - o o
04 - o - -
05 - o - o
06 - o o -
07 - o o o
08 o - - -
09 o - - o
10 o - o -
11 o - o o
12 o o - -
13 o o - o
14 o o o -
15 o o o o
