Roland SPD-SX PRO - Modulation Effects; Phaser; Script 100

Effect List (English)
176
Modulation effects
Phaser(P.176)
Small Phaser(P.177)
Script 100(P.177)
Step Phaser(P.178)
Infinite Phaser(P.178)
Ring Modulator(P.179)
Tremolo(P.180)
Auto Pan(P.180)
Slicer(P.181)
Phaser
This is a stereo phaser. A phase-shifted sound is added to the original sound and modulated.
Parameter
Value
Explanation
Mode
4-STAGE, 8-STAGE, 12-
STAGE
Number of stages in the phaser
Manual
0–127
Center frequency at which the sound is modulated
Tempo Sync
OFF, ON
If this is ON, the rate synchronizes with the tempo of the rhythm.
Ø KIT TEMPO(P.33)
Rate (Hz)
0.05–10.00 [Hz]
Modulation rate
Rate (note)
Note
Ø Note(P.203)
Depth
0–127
Depth of modulation
Polarity
INVERSE, SYNCHRO
Selects whether the left and right phase of the modulation will be the same or the
opposite.
INVERSE: The left and right phase will be opposite.
When using a mono source, this spreads the sound.
SYNCHRO: The left and right phase will be the same.
Select this when inputting a stereo source.
Resonance
0–127
Amount of feedback
Cross
Feedback
-98–+98 [%]
Adjusts the proportion of the phaser sound that is fed back into the effect. Negative (-)
settings will invert the phase.
Mix (*1)
0–127
Level of the phase-shifted sound
Low Gain
-15–+15 [dB]
Gain of the low range
High Gain
-15–+15 [dB]
Gain of the high range
Level
0–127
Output Level
*1: This parameter corresponds to MFX Ctrl. For details, refer to “De MFX bedienen met de PAD EDIT [1] [2]-regelaars (MFX
Ctrl)(P.204)”.
*1: This parameter corresponds to MASTER EFFECT CTRL. For details, refer to “Het MASTER EFFECT bedienen met de MASTER
EFFECT-regelaar (MASTER EFFECT CTRL)(P.205)”.
