Roland V-Synth Supplementary Guide

11
MIDI Implementation
| 00 6C | 0aaa aaaa | Matrix Control 7 Sens 2 (1 - 127) |
| | | -63 - +63 |
|-------------+-----------+----------------------------------------------------|
| 00 6D | 0aaa aaaa | Matrix Control 8 Source (0 - 108) |
| | | OFF, CC01 - CC31, CC33 - CC95, BEND, AFT, |
| | | +PAD-X, +PAD-Y, PAD-X, PAD-Y, TRIP-R, |
| | | BEAM-L, BEAM-R, KNOB1, KNOB2, VELO, KEYF |
| 00 6E | 0aaa aaaa | Matrix Control 8 Dest 1 (0 - 78) |
| | | OFF, |
| | | OSC1-PITCH, OSC1-TIME/PW, OSC1-FORMA/FAT, |
| | | OSC1-LVL, |
| | | OSC1-PENV-ATK, OSC1-PENV-DCY, OSC1-PENV-REL, |
| | | OSC1-TENV-ATK, OSC1-TENV-DCY, OSC1-TENV-REL, |
| | | OSC1-FENV-ATK, OSC1-FENV-DCY, OSC1-FENV-REL, |
| | | OSC1-AENV-ATK, OSC1-AENV-DCY, OSC1-AENV-REL, |
| | | OSC1-LFO-RATE, OSC1-LFO-PCH, OSC1-LFO-TM/PW, |
| | | OSC1-LFO-FR/FT, OSC1-LFO-LVL, |
| | | OSC2-PITCH, OSC2-TIME/PW, OSC2-FORMA/FAT, |
| | | OSC2-LVL, |
| | | OSC2-PENV-ATK, OSC2-PENV-DCY, OSC2-PENV-REL, |
| | | OSC2-TENV-ATK, OSC2-TENV-DCY, OSC2-TENV-REL, |
| | | OSC2-FENV-ATK, OSC2-FENV-DCY, OSC2-FENV-REL, |
| | | OSC2-AENV-ATK, OSC2-AENV-DCY, OSC2-AENV-REL, |
| | | OSC2-LFO-RATE, OSC2-LFO-PCH, OSC2-LFO-TM/PW, |
| | | OSC2-LFO-FR/FT, OSC2-LFO-LVL, |
| | | CSM1-PRM1, CSM1-PRM2, |
| | | CSM1-ENV1-ATK, CSM1-ENV1-DCY, CSM1-ENV1-REL, |
| | | CSM1-ENV2-ATK, CSM1-ENV2-DCY, CSM1-ENV2-REL, |
| | | CSM1-LFO-RATE, CSM1-LFO-PRM1, CSM1-LFO-PRM2, |
| | | CSM2-PRM1, CSM2-PRM2, |
| | | CSM2-ENV1-ATK, CSM2-ENV1-DCY, CSM2-ENV1-REL, |
| | | CSM2-ENV2-ATK, CSM2-ENV2-DCY, CSM2-ENV2-REL, |
| | | CSM2-LFO-RATE, CSM2-LFO-PRM1, CSM2-LFO-PRM2, |
| | | TVA-LVL, |
| | | TVA-ENV-ATK, TVA-ENV-DCY, TVA-ENV-REL, |
| | | TVA-LFO-RATE, TVA-LFO-LVL, TVA-LFO-PAN, |
| | | MFX-SEND, CHO-SEND, REV-SEND, |
| | | MFX-PRM1, MFX-PRM2, MFX-PRM3, |
| | | TVA-PAN |
| 00 6F | 0aaa aaaa | Matrix Control 8 Sens 1 (1 - 127) |
| | | -63 - +63 |
| 00 70 | 0aaa aaaa | Matrix Control 8 Dest 2 (0 - 78) |
| | | OFF, |
| | | OSC1-PITCH, OSC1-TIME/PW, OSC1-FORMA/FAT, |
| | | OSC1-LVL, |
| | | OSC1-PENV-ATK, OSC1-PENV-DCY, OSC1-PENV-REL, |
| | | OSC1-TENV-ATK, OSC1-TENV-DCY, OSC1-TENV-REL, |
| | | OSC1-FENV-ATK, OSC1-FENV-DCY, OSC1-FENV-REL, |
| | | OSC1-AENV-ATK, OSC1-AENV-DCY, OSC1-AENV-REL, |
| | | OSC1-LFO-RATE, OSC1-LFO-PCH, OSC1-LFO-TM/PW, |
| | | OSC1-LFO-FR/FT, OSC1-LFO-LVL, |
| | | OSC2-PITCH, OSC2-TIME/PW, OSC2-FORMA/FAT, |
| | | OSC2-LVL, |
| | | OSC2-PENV-ATK, OSC2-PENV-DCY, OSC2-PENV-REL, |
| | | OSC2-TENV-ATK, OSC2-TENV-DCY, OSC2-TENV-REL, |
| | | OSC2-FENV-ATK, OSC2-FENV-DCY, OSC2-FENV-REL, |
| | | OSC2-AENV-ATK, OSC2-AENV-DCY, OSC2-AENV-REL, |
| | | OSC2-LFO-RATE, OSC2-LFO-PCH, OSC2-LFO-TM/PW, |
| | | OSC2-LFO-FR/FT, OSC2-LFO-LVL, |
| | | CSM1-PRM1, CSM1-PRM2, |
| | | CSM1-ENV1-ATK, CSM1-ENV1-DCY, CSM1-ENV1-REL, |
| | | CSM1-ENV2-ATK, CSM1-ENV2-DCY, CSM1-ENV2-REL, |
| | | CSM1-LFO-RATE, CSM1-LFO-PRM1, CSM1-LFO-PRM2, |
| | | CSM2-PRM1, CSM2-PRM2, |
| | | CSM2-ENV1-ATK, CSM2-ENV1-DCY, CSM2-ENV1-REL, |
| | | CSM2-ENV2-ATK, CSM2-ENV2-DCY, CSM2-ENV2-REL, |
| | | CSM2-LFO-RATE, CSM2-LFO-PRM1, CSM2-LFO-PRM2, |
| | | TVA-LVL, |
| | | TVA-ENV-ATK, TVA-ENV-DCY, TVA-ENV-REL, |
| | | TVA-LFO-RATE, TVA-LFO-LVL, TVA-LFO-PAN, |
| | | MFX-SEND, CHO-SEND, REV-SEND, |
| | | MFX-PRM1, MFX-PRM2, MFX-PRM3, |
| | | TVA-PAN |
| 00 71 | 0aaa aaaa | Matrix Control 8 Sens 2 (1 - 127) |
| | | -63 - +63 |
|-------------+----------------------------------------------------------------|
| 00 00 00 72 | Total Size |
+------------------------------------------------------------------------------+
❍ Patch MFX
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 | 0aaa aaaa | MFX Type (0 - 41) |
| 00 01 | 0aaa aaaa | MFX Master Level (0 - 127) |
| 00 02 | 0aaa aaaa | MFX Chorus Send Level (0 - 127) |
| 00 03 | 0aaa aaaa | MFX Reverb Send Level (0 - 127) |
|-------------+-----------+----------------------------------------------------|
|# 00 04 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 1 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 08 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 2 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 0C | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 3 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 10 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 4 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 14 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 5 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 18 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 6 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 1C | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 7 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 20 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 8 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 24 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 9 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 28 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 10 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 2C | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 11 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 30 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 12 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 34 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 13 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 38 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 14 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 3C | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 15 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 40 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 16 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 44 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 17 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 48 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 18 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 4C | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 19 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 50 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 20 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 54 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 21 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 58 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 22 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 5C | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 23 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 60 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 24 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 64 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 25 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 68 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 26 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 6C | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 27 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 70 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 28 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 74 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 29 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 78 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 30 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 7C | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 31 (12768 - 52768) |
| | | -20000 - +20000 |
|# 01 00 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 32 (12768 - 52768) |
| | | -20000 - +20000 |
|-------------+----------------------------------------------------------------|
| 00 00 01 04 | Total Size |
+------------------------------------------------------------------------------+
❍Patch Chorus
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 | 0000 aaaa | Chorus Type (0 - 8) |
| 00 01 | 0aaa aaaa | Chorus Master Level (0 - 127) |
| 00 02 | 0aaa aaaa | Chorus Reverb Send Level (0 - 127) |
|-------------+-----------+----------------------------------------------------|
|# 00 03 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Chorus Parameter 1 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 07 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Chorus Parameter 2 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 0B | 0000 aaaa | |
| | 0000 bbbb | |
