Page #12 background imageLoading...
Page #12 background image
12
MIDI Implementation
| | 0000 cccc | |
| | 0000 dddd | Chorus Parameter 3 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 0F | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Chorus Parameter 4 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 13 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Chorus Parameter 5 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 17 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Chorus Parameter 6 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 1B | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Chorus Parameter 7 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 1F | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Chorus Parameter 8 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 23 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Chorus Parameter 9 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 27 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Chorus Parameter 10 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 2B | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Chorus Parameter 11 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 2F | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Chorus Parameter 12 (12768 - 52768) |
| | | -20000 - +20000 |
|-------------+----------------------------------------------------------------|
| 00 00 00 33 | Total Size |
+------------------------------------------------------------------------------+
āPatch Reverb
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 | 0000 aaaa | Reverb Type (0 - 10) |
| 00 01 | 0aaa aaaa | Reverb Master Level (0 - 127) |
|-------------+-----------+----------------------------------------------------|
|# 00 02 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 1 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 06 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 2 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 0A | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 3 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 0E | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 4 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 12 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 5 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 16 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 6 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 1A | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 7 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 1E | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 8 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 22 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 9 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 26 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 10 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 2A | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 11 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 2E | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 12 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 32 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 13 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 36 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 14 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 3A | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 15 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 3E | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 16 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 42 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 17 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 46 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 18 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 4A | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 19 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 4E | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 20 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 52 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 21 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 56 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 22 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 5A | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 23 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 5E | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 24 (12768 - 52768) |
| | | -20000 - +20000 |
|-------------+----------------------------------------------------------------|
| 00 00 00 62 | Total Size |
+------------------------------------------------------------------------------+
āPatch Oscillator
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 | 0000 00aa | Structure Type (0 - 2) |
| | | 1 - 3 |
|-------------+-----------+----------------------------------------------------|
| 00 01 | 0000 000a | MOD Switch (0 - 1) |
| | | OFF, ON |
| 00 02 | 0000 0aaa | MOD Type (0 - 4) |
| | | MIX, RING(AM), FM, ENV RING, |
| | | OSC SYNC |
| 00 03 | 0aaa aaaa | MOD Original Level (0 - 127) |
| 00 04 | 0aaa aaaa | MOD Attack Time (0 - 127) |
| 00 05 | 0aaa aaaa | MOD Release Time (0 - 127) |
|-------------+-----------+----------------------------------------------------|
| 00 06 | 0000 000a | TVA Switch (0 - 1) |
| | | OFF, ON |
| 00 07 | 0aaa aaaa | TVA Level (0 - 127) |
| 00 08 | 00aa aaaa | TVA Level Keyfollow (44 - 84) |
| | | -200 - +200 |
| 00 09 | 0aaa aaaa | TVA Level LFO Depth (1 - 127) |
| | | -63 - +63 |
| 00 0A | 0aaa aaaa | TVA Pan (0 - 127) |
| | | L64 - 63R |
| 00 0B | 00aa aaaa | TVA Pan Keyfollow (44 - 84) |
| | | -200 - +200 |
| 00 0C | 0aaa aaaa | TVA Pan LFO Depth (1 - 127) |
| | | -63 - +63 |
|-------------+-----------+----------------------------------------------------|
| 00 0D | 0aaa aaaa | MFX Send Level (0 - 127) |
| 00 0E | 0aaa aaaa | Chorus Send Level (0 - 127) |
| 00 0F | 0aaa aaaa | Reverb Send Level (0 - 127) |
| 00 10 | 0000 00aa | Output Assign (0 - 2) |
| | | MULTI, MAIN, DIR |
|-------------+-----------+----------------------------------------------------|
| 00 11 | 0000 000a | OSC 1 Switch (0 - 1) |
| | | OFF, ON |
| 00 12 | 0000 00aa | OSC 1 Type (0 - 2) |
| | | ANALOG, PCM, EXTIN |
| 00 13 | 000a aaaa | OSC 1 Wave Gain (52 - 76) |
| | | -12 - +12 [dB] |
| 00 14 | 0aaa aaaa | OSC 1 Pitch (1 - 127) |
| | | -63 - +63 |
| 00 15 | 00aa aaaa | OSC 1 Pitch Keyfollow (44 - 84) |
| | | -200 - +200 |
| 00 16 | 0aaa aaaa | OSC 1 Pitch LFO Depth (1 - 127) |
| | | -63 - +63 |
| 00 17 | 0aaa aaaa | OSC 1 Pitch Envelope Depth (1 - 127) |
| | | -63 - +63 |
| 00 18 | 0aaa aaaa | OSC 1 Coarse Tune (16 - 112) |
| | | -48 - +48 |
| 00 19 | 0aaa aaaa | OSC 1 Fine Tune (14 - 114) |
| | | -50 - +50 [cent] |
| 00 1A | 000a aaaa | OSC 1 Random Pitch Depth (0 - 30) |
| | | 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, |
| | | 10, 20, 30, 40, 50, 60, 70, 80, |
| | | 90, 100, 200, 300, 400, 500, |
| | | 600, 700, 800, 900, 1000, 1100, |
| | | 1200 |
| 00 1B | 0aaa aaaa | OSC 1 Level (0 - 127) |
| 00 1C | 00aa aaaa | OSC 1 Level Keyfollow (44 - 84) |
| | | -200 - +200 |
| 00 1D | 0aaa aaaa | OSC 1 Level LFO Depth (1 - 127) |
| | | -63 - +63 |
|-------------+-----------+----------------------------------------------------|
| 00 1E | 0000 aaaa | OSC 1 Analog Wavefrom (0 - 13) |
| | | SAW, SQUARE, TRIANGLE, SINE, RAMP, JUNO, |
| | | HQ-SAW, HQ-SQUARE, NOISE, |
| | | LA-SAW, LA-SQUARE, |
| | | SUPER-SAW, FBACK-OSC, X-MOD-OSC |
| 00 1F | 00aa aaaa | OSC 1 Impact (0 - 40) |
| | | 0.0 - 4.0 |
| 00 20 | 0aaa aaaa | OSC 1 Pulse Width (1 - 127) |
| | | -63 - +63 |
| 00 21 | 00aa aaaa | OSC 1 Pulse Width Keyfollow (44 - 84) |
| | | -200 - +200 |
| 00 22 | 0aaa aaaa | OSC 1 Pulse Width LFO Depth (1 - 127) |
| | | -63 - +63 |
| 00 23 | 0aaa aaaa | OSC 1 Pulse Width Envelope Depth (1 - 127) |
| | | -63 - +63 |
| 00 24 | 0aaa aaaa | OSC 1 Fat (0 - 127) |
| 00 25 | 00aa aaaa | OSC 1 Fat Keyfollow (44 - 84) |
| | | -200 - +200 |
| 00 26 | 0aaa aaaa | OSC 1 Fat LFO Depth (1 - 127) |
| | | -63 - +63 |
| 00 27 | 0aaa aaaa | OSC 1 Fat Envelope Depth (1 - 127) |
| | | -63 - +63 |
|-------------+-----------+----------------------------------------------------|
