Roland V-Synth Supplementary Guide

13
MIDI Implementation
|# 00 28 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | OSC 1 Wave Number (0 - 999) |
| | | OFF, 1 - 999 |
|# 00 2C | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | |
| | 0000 eeee | |
| | 0000 ffff | |
| | 0000 gggg | |
| | 0000 hhhh | OSC 1 Start Offset |
| | | 0000000h - FFFFFFFh |
| 00 34 | 0aaa aaaa | OSC 1 Time (1 - 127) |
| | | -63 - +63 |
| 00 35 | 00aa aaaa | OSC 1 Time Keyfollow (44 - 84) |
| | | -200 - +200 |
| 00 36 | 0aaa aaaa | OSC 1 Time LFO Depth (1 - 127) |
| | | -63 - +63 |
| 00 37 | 0aaa aaaa | OSC 1 Time Envelope Depth (1 - 127) |
| | | -63 - +63 |
| 00 38 | 0000 00aa | OSC 1 Time Offset (0 - 2) |
| | | BWD, ZERO, FWD |
| 00 39 | 0aaa aaaa | OSC 1 Formant (1 - 127) |
| | | -63 - +63 |
| 00 3A | 00aa aaaa | OSC 1 Formant Keyfollow (44 - 84) |
| | | -200 - +200 |
| 00 3B | 0aaa aaaa | OSC 1 Formant LFO Depth (1 - 127) |
| | | -63 - +63 |
| 00 3C | 0aaa aaaa | OSC 1 Formant Envelope Depth (1 - 127) |
| | | -63 - +63 |
| 00 3D | 0000 000a | OSC 1 Tempo Sync Sw (0 - 1) |
| | | OFF, ON |
| 00 3E | 0000 000a | OSC 1 Robot Voice Sw (0 - 1) |
| | | OFF, ON |
| 00 3F | 0000 00aa | OSC 1 Playback Mode (0 - 3) |
| | | RETRIGGER, LEGATO, STEP, EVENT |
| 00 40 | 0000 000a | OSC 1 Loop Sw (0 - 1) |
| | | OFF, ON |
| 00 41 | 0000 000a | OSC 1 Vari Sw (0 - 1) |
| | | OFF, ON |
| 00 42 | 0aaa aaaa | OSC 1 Energy (0 - 127) |
| | | OFF, 1 - 127 |
| 00 43 | 0000 000a | OSC 1 Time Trip Sw (0 - 1) |
| | | OFF, ON |
| 00 44 | 0000 000a | OSC 1 Time Trip Beat Keep (0 - 1) |
| | | OFF, ON |
|-------------+-----------+----------------------------------------------------|
| 00 45 | 0000 000a | OSC 2 Switch (0 - 1) |
| | | OFF, ON |
| 00 46 | 0000 00aa | OSC 2 Type (0 - 2) |
| | | ANALOG, PCM, EXTIN |
| 00 47 | 000a aaaa | OSC 2 Wave Gain (52 - 76) |
| | | -12 - +12 [dB] |
| 00 48 | 0aaa aaaa | OSC 2 Pitch (1 - 127) |
| | | -63 - +63 |
| 00 49 | 00aa aaaa | OSC 2 Pitch Keyfollow (44 - 84) |
| | | -200 - +200 |
| 00 4A | 0aaa aaaa | OSC 2 Pitch LFO Depth (1 - 127) |
| | | -63 - +63 |
| 00 4B | 0aaa aaaa | OSC 2 Pitch Envelope Depth (1 - 127) |
| | | -63 - +63 |
| 00 4C | 0aaa aaaa | OSC 2 Coarse Tune (16 - 112) |
| | | -48 - +48 |
| 00 4D | 0aaa aaaa | OSC 2 Fine Tune (14 - 114) |
| | | -50 - +50 [cent] |
| 00 4E | 000a aaaa | OSC 2 Random Pitch Depth (0 - 30) |
| | | 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, |
| | | 10, 20, 30, 40, 50, 60, 70, 80, |
| | | 90, 100, 200, 300, 400, 500, |
| | | 600, 700, 800, 900, 1000, 1100, |
| | | 1200 |
| 00 4F | 0aaa aaaa | OSC 2 Level (0 - 127) |
| 00 50 | 00aa aaaa | OSC 2 Level Keyfollow (44 - 84) |
| | | -200 - +200 |
| 00 51 | 0aaa aaaa | OSC 2 Level LFO Depth (1 - 127) |
| | | -63 - +63 |
|-------------+-----------+----------------------------------------------------|
| 00 52 | 0000 aaaa | OSC 2 Analog Wavefrom (0 - 13) |
| | | SAW, SQUARE, TRIANGLE, SINE, RAMP, JUNO, |
| | | HQ-SAW, HQ-SQUARE, NOISE, |
| | | LA-SAW, LA-SQUARE, |
| | | SUPER-SAW, FBACK-OSC, X-MOD-OSC |
| 00 53 | 00aa aaaa | OSC 2 Impact (0 - 40) |
| | | 0.0 - 4.0 |
| 00 54 | 0aaa aaaa | OSC 2 Pulse Width (1 - 127) |
| | | -63 - +63 |
| 00 55 | 00aa aaaa | OSC 2 Pulse Width Keyfollow (44 - 84) |
| | | -200 - +200 |
| 00 56 | 0aaa aaaa | OSC 2 Pulse Width LFO Depth (1 - 127) |
| | | -63 - +63 |
| 00 57 | 0aaa aaaa | OSC 2 Pulse Width Envelope Depth (1 - 127) |
| | | -63 - +63 |
| 00 58 | 0aaa aaaa | OSC 2 Fat (0 - 127) |
| 00 59 | 00aa aaaa | OSC 2 Fat Keyfollow (44 - 84) |
| | | -200 - +200 |
| 00 5A | 0aaa aaaa | OSC 2 Fat LFO Depth (1 - 127) |
| | | -63 - +63 |
| 00 5B | 0aaa aaaa | OSC 2 Fat Envelope Depth (1 - 127) |
| | | -63 - +63 |
|-------------+-----------+----------------------------------------------------|
|# 00 5C | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | OSC 2 Wave Number (0 - 999) |
| | | OFF, 1 - 999 |
|# 00 60 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | |
| | 0000 eeee | |
| | 0000 ffff | |
| | 0000 gggg | |
| | 0000 hhhh | OSC 2 Start Offset |
| | | 0000000h - FFFFFFFh |
| 00 68 | 0aaa aaaa | OSC 2 Time (1 - 127) |
| | | -63 - +63 |
| 00 69 | 00aa aaaa | OSC 2 Time Keyfollow (44 - 84) |
| | | -200 - +200 |
| 00 6A | 0aaa aaaa | OSC 2 Time LFO Depth (1 - 127) |
| | | -63 - +63 |
| 00 6B | 0aaa aaaa | OSC 2 Time Envelope Depth (1 - 127) |
| | | -63 - +63 |
| 00 6C | 0000 00aa | OSC 2 Time Offset (0 - 2) |
| | | BWD, ZERO, FWD |
| 00 6D | 0aaa aaaa | OSC 2 Formant (1 - 127) |
| | | -63 - +63 |
| 00 6E | 00aa aaaa | OSC 2 Formant Keyfollow (44 - 84) |
| | | -200 - +200 |
| 00 6F | 0aaa aaaa | OSC 2 Formant LFO Depth (1 - 127) |
| | | -63 - +63 |
| 00 70 | 0aaa aaaa | OSC 2 Formant Envelope Depth (1 - 127) |
| | | -63 - +63 |
| 00 71 | 0000 000a | OSC 2 Tempo Sync Sw (0 - 1) |
| | | OFF, ON |
| 00 72 | 0000 000a | OSC 2 Robot Voice Sw (0 - 1) |
| | | OFF, ON |
| 00 73 | 0000 00aa | OSC 2 Playback Mode (0 - 3) |
| | | RETRIGGER, LEGATO, STEP, EVENT |
| 00 74 | 0000 000a | OSC 2 Loop Sw (0 - 1) |
| | | OFF, ON |
| 00 75 | 0000 000a | OSC 2 Vari Sw (0 - 1) |
| | | OFF, ON |
| 00 76 | 0aaa aaaa | OSC 2 Energy (0 - 127) |
| | | OFF, 1 - 127 |
| 00 77 | 0000 000a | OSC 2 Time Trip Sw (0 - 1) |
| | | OFF, ON |
| 00 78 | 0000 000a | OSC 2 Time Trip Beat Keep (0 - 1) |
| | | OFF, ON |
|-------------+-----------+----------------------------------------------------|
| 00 79 | 0aaa aaaa | OSC 1 Detune (1 - 127) |
| | | -63 - +63 |
| 00 7A | 0000 00aa | OSC 1 Sub Oscillator Octave (0 - 3) |
| | | OFF, -2, -1, 0 |
| 00 7B | 0aaa aaaa | OSC 1 Sub Oscillator Level (0 - 127) |
|-------------+-----------+----------------------------------------------------|
| 00 7C | 0aaa aaaa | OSC 2 Detune (1 - 127) |
| | | -63 - +63 |
| 00 7D | 0000 00aa | OSC 2 Sub Oscillator Octave (0 - 3) |
| | | OFF, -2, -1, 0 |
| 00 7E | 0aaa aaaa | OSC 2 Sub Oscillator Level (0 - 127) |
|-------------+----------------------------------------------------------------|
| 00 00 00 7F | Total Size |
+------------------------------------------------------------------------------+
❍Patch Envelope
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
|# 00 00 | 0000 aaaa | |
| | 0000 bbbb | Env 1 Attack Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
|# 00 02 | 0000 aaaa | |
| | 0000 bbbb | Env 1 Decay Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 00 04 | 0aaa aaaa | Env 1 Sustine (0 - 127) |
|# 00 05 | 0000 aaaa | |
| | 0000 bbbb | Env 1 Release Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 00 07 | 0000 0aaa | Env 1 Velocity Curve (0 - 7) |
| | | FIXED, 1 - 7 |
| 00 08 | 0aaa aaaa | Env 1 Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 09 | 0aaa aaaa | Env 1 Attack Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 0A | 0aaa aaaa | Env 1 Decay Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 0B | 0aaa aaaa | Env 1 Release Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 0C | 00aa aaaa | Env 1 Time Keyfollow (44 - 84) |
| | | -200 - +200 |
|-------------+-----------+----------------------------------------------------|
|# 00 0D | 0000 aaaa | |
| | 0000 bbbb | Env 2 Attack Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
|# 00 0F | 0000 aaaa | |
| | 0000 bbbb | Env 2 Decay Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 00 11 | 0aaa aaaa | Env 2 Sustine (0 - 127) |
|# 00 12 | 0000 aaaa | |
| | 0000 bbbb | Env 2 Release Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 00 14 | 0000 0aaa | Env 2 Velocity Curve (0 - 7) |
| | | FIXED, 1 - 7 |
| 00 15 | 0aaa aaaa | Env 2 Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 16 | 0aaa aaaa | Env 2 Attack Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 17 | 0aaa aaaa | Env 2 Decay Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 18 | 0aaa aaaa | Env 2 Release Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 19 | 00aa aaaa | Env 2 Time Keyfollow (44 - 84) |
| | | -200 - +200 |
|-------------+-----------+----------------------------------------------------|
|# 00 1A | 0000 aaaa | |
| | 0000 bbbb | Env 3 Attack Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
|# 00 1C | 0000 aaaa | |
| | 0000 bbbb | Env 3 Decay Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 00 1E | 0aaa aaaa | Env 3 Sustine (0 - 127) |
|# 00 1F | 0000 aaaa | |
| | 0000 bbbb | Env 3 Release Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 00 21 | 0000 0aaa | Env 3 Velocity Curve (0 - 7) |
| | | FIXED, 1 - 7 |
| 00 22 | 0aaa aaaa | Env 3 Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 23 | 0aaa aaaa | Env 3 Attack Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 24 | 0aaa aaaa | Env 3 Decay Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 25 | 0aaa aaaa | Env 3 Release Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 26 | 00aa aaaa | Env 3 Time Keyfollow (44 - 84) |
| | | -200 - +200 |
|-------------+-----------+----------------------------------------------------|
|# 00 27 | 0000 aaaa | |
| | 0000 bbbb | Env 4 Attack Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
|# 00 29 | 0000 aaaa | |
| | 0000 bbbb | Env 4 Decay Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 00 2B | 0aaa aaaa | Env 4 Sustine (0 - 127) |
|# 00 2C | 0000 aaaa | |
| | 0000 bbbb | Env 4 Release Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 00 2E | 0000 0aaa | Env 4 Velocity Curve (0 - 7) |
| | | FIXED, 1 - 7 |
| 00 2F | 0aaa aaaa | Env 4 Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 30 | 0aaa aaaa | Env 4 Attack Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 31 | 0aaa aaaa | Env 4 Decay Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 32 | 0aaa aaaa | Env 4 Release Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 33 | 00aa aaaa | Env 4 Time Keyfollow (44 - 84) |
| | | -200 - +200 |
|-------------+-----------+----------------------------------------------------|
|# 00 34 | 0000 aaaa | |
| | 0000 bbbb | Env 5 Attack Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
|# 00 36 | 0000 aaaa | |
| | 0000 bbbb | Env 5 Decay Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 00 38 | 0aaa aaaa | Env 5 Sustine (0 - 127) |
|# 00 39 | 0000 aaaa | |
| | 0000 bbbb | Env 5 Release Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 00 3B | 0000 0aaa | Env 5 Velocity Curve (0 - 7) |
| | | FIXED, 1 - 7 |
