Roland V-Synth Supplementary Guide

14
MIDI Implementation
| 00 3C | 0aaa aaaa | Env 5 Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 3D | 0aaa aaaa | Env 5 Attack Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 3E | 0aaa aaaa | Env 5 Decay Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 3F | 0aaa aaaa | Env 5 Release Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 40 | 00aa aaaa | Env 5 Time Keyfollow (44 - 84) |
| | | -200 - +200 |
|-------------+-----------+----------------------------------------------------|
|# 00 41 | 0000 aaaa | |
| | 0000 bbbb | Env 6 Attack Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
|# 00 43 | 0000 aaaa | |
| | 0000 bbbb | Env 6 Decay Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 00 45 | 0aaa aaaa | Env 6 Sustine (0 - 127) |
|# 00 46 | 0000 aaaa | |
| | 0000 bbbb | Env 6 Release Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 00 48 | 0000 0aaa | Env 6 Velocity Curve (0 - 7) |
| | | FIXED, 1 - 7 |
| 00 49 | 0aaa aaaa | Env 6 Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 4A | 0aaa aaaa | Env 6 Attack Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 4B | 0aaa aaaa | Env 6 Decay Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 4C | 0aaa aaaa | Env 6 Release Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 4D | 00aa aaaa | Env 6 Time Keyfollow (44 - 84) |
| | | -200 - +200 |
|-------------+-----------+----------------------------------------------------|
|# 00 4E | 0000 aaaa | |
| | 0000 bbbb | Env 7 Attack Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
|# 00 50 | 0000 aaaa | |
| | 0000 bbbb | Env 7 Decay Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 00 52 | 0aaa aaaa | Env 7 Sustine (0 - 127) |
|# 00 53 | 0000 aaaa | |
| | 0000 bbbb | Env 7 Release Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 00 55 | 0000 0aaa | Env 7 Velocity Curve (0 - 7) |
| | | FIXED, 1 - 7 |
| 00 56 | 0aaa aaaa | Env 7 Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 57 | 0aaa aaaa | Env 7 Attack Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 58 | 0aaa aaaa | Env 7 Decay Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 59 | 0aaa aaaa | Env 7 Release Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 5A | 00aa aaaa | Env 7 Time Keyfollow (44 - 84) |
| | | -200 - +200 |
|-------------+-----------+----------------------------------------------------|
|# 00 5B | 0000 aaaa | |
| | 0000 bbbb | Env 8 Attack Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
|# 00 5D | 0000 aaaa | |
| | 0000 bbbb | Env 8 Decay Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 00 5F | 0aaa aaaa | Env 8 Sustine (0 - 127) |
|# 00 60 | 0000 aaaa | |
| | 0000 bbbb | Env 8 Release Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 00 62 | 0000 0aaa | Env 8 Velocity Curve (0 - 7) |
| | | FIXED, 1 - 7 |
| 00 63 | 0aaa aaaa | Env 8 Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 64 | 0aaa aaaa | Env 8 Attack Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 65 | 0aaa aaaa | Env 8 Decay Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 66 | 0aaa aaaa | Env 8 Release Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 67 | 00aa aaaa | Env 8 Time Keyfollow (44 - 84) |
| | | -200 - +200 |
|-------------+-----------+----------------------------------------------------|
|# 00 68 | 0000 aaaa | |
| | 0000 bbbb | Env 9 Attack Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
|# 00 6A | 0000 aaaa | |
| | 0000 bbbb | Env 9 Decay Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 00 6C | 0aaa aaaa | Env 9 Sustine (0 - 127) |
|# 00 6D | 0000 aaaa | |
| | 0000 bbbb | Env 9 Release Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 00 6F | 0000 0aaa | Env 9 Velocity Curve (0 - 7) |
| | | FIXED, 1 - 7 |
| 00 70 | 0aaa aaaa | Env 9 Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 71 | 0aaa aaaa | Env 9 Attack Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 72 | 0aaa aaaa | Env 9 Decay Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 73 | 0aaa aaaa | Env 9 Release Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 74 | 00aa aaaa | Env 9 Time Keyfollow (44 - 84) |
| | | -200 - +200 |
|-------------+-----------+----------------------------------------------------|
|# 00 75 | 0000 aaaa | |
| | 0000 bbbb | Env 10 Attack Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
|# 00 77 | 0000 aaaa | |
| | 0000 bbbb | Env 10 Decay Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 00 79 | 0aaa aaaa | Env 10 Sustine (0 - 127) |
|# 00 7A | 0000 aaaa | |
| | 0000 bbbb | Env 10 Release Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 00 7C | 0000 0aaa | Env 10 Velocity Curve (0 - 7) |
| | | FIXED, 1 - 7 |
| 00 7D | 0aaa aaaa | Env 10 Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 7E | 0aaa aaaa | Env 10 Attack Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 7F | 0aaa aaaa | Env 10 Decay Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 00 | 0aaa aaaa | Env 10 Release Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 01 | 00aa aaaa | Env 10 Time Keyfollow (44 - 84) |
| | | -200 - +200 |
|-------------+-----------+----------------------------------------------------|
|# 01 02 | 0000 aaaa | |
| | 0000 bbbb | Env 11 Attack Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
|# 01 04 | 0000 aaaa | |
| | 0000 bbbb | Env 11 Decay Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 01 06 | 0aaa aaaa | Env 11 Sustine (0 - 127) |
|# 01 07 | 0000 aaaa | |
| | 0000 bbbb | Env 11 Release Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 01 09 | 0000 0aaa | Env 11 Velocity Curve (0 - 7) |
| | | FIXED, 1 - 7 |
| 01 0A | 0aaa aaaa | Env 11 Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 0B | 0aaa aaaa | Env 11 Attack Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 0C | 0aaa aaaa | Env 11 Decay Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 0D | 0aaa aaaa | Env 11 Release Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 0E | 00aa aaaa | Env 11 Time Keyfollow (44 - 84) |
| | | -200 - +200 |
|-------------+-----------+----------------------------------------------------|
|# 01 0F | 0000 aaaa | |
| | 0000 bbbb | Env 12 Attack Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
|# 01 11 | 0000 aaaa | |
| | 0000 bbbb | Env 12 Decay Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 01 13 | 0aaa aaaa | Env 12 Sustine (0 - 127) |
|# 01 14 | 0000 aaaa | |
| | 0000 bbbb | Env 12 Release Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 01 16 | 0000 0aaa | Env 12 Velocity Curve (0 - 7) |
| | | FIXED, 1 - 7 |
| 01 17 | 0aaa aaaa | Env 12 Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 18 | 0aaa aaaa | Env 12 Attack Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 19 | 0aaa aaaa | Env 12 Decay Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 1A | 0aaa aaaa | Env 12 Release Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 1B | 00aa aaaa | Env 12 Time Keyfollow (44 - 84) |
| | | -200 - +200 |
|-------------+-----------+----------------------------------------------------|
|# 01 1C | 0000 aaaa | |
| | 0000 bbbb | Env 13 Attack Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
|# 01 1E | 0000 aaaa | |
| | 0000 bbbb | Env 13 Decay Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 01 20 | 0aaa aaaa | Env 13 Sustine (0 - 127) |
|# 01 21 | 0000 aaaa | |
| | 0000 bbbb | Env 13 Release Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 01 23 | 0000 0aaa | Env 13 Velocity Curve (0 - 7) |
| | | FIXED, 1 - 7 |
| 01 24 | 0aaa aaaa | Env 13 Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 25 | 0aaa aaaa | Env 13 Attack Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 26 | 0aaa aaaa | Env 13 Decay Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 27 | 0aaa aaaa | Env 13 Release Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 28 | 00aa aaaa | Env 13 Time Keyfollow (44 - 84) |
| | | -200 - +200 |
|-------------+----------------------------------------------------------------|
| 00 00 01 29 | Total Size |
+------------------------------------------------------------------------------+
+--------------------------------+
| ENV 1 | OSC1 Pitch |
| ENV 2 | OSC1 Time/Pulse Width |
| ENV 3 | OSC1 Formant/Fat |
| ENV 4 | OSC1 Level |
| ENV 5 | OSC2 Pitch |
| ENV 6 | OSC2 Time/Pulse Width |
| ENV 7 | OSC2 Formant/Fat |
| ENV 8 | OSC2 Level |
| ENV 9 | COSM1 Parameter 1 |
| ENV 10 | COSM1 Parameter 2 |
| ENV 11 | COSM2 Parameter 1 |
| ENV 12 | COSM2 Parameter 2 |
| ENV 13 | TVA Level |
+--------------------------------+
❍Patch LFO
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 | 0000 0aaa | LFO 1 Waveform (0 - 7) |
| | | SIN, TRI, SAW, SQR, RND, TRP, |
| | | S&H, CHS |
|# 00 01 | 0000 aaaa | |
| | 0000 bbbb | LFO 1 Rate (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 00 03 | 0000 0aaa | LFO 1 Offset (0 - 4) |
| | | -100, -50, 0, +50, +100 |
| 00 04 | 0aaa aaaa | LFO 1 Delay Time (0 - 127) |
| 00 05 | 0000 00aa | LFO 1 Fade Mode (0 - 3) |
| | | ON-IN, ON-OUT, OFF-IN, OFF-OUT |
| 00 06 | 0aaa aaaa | LFO 1 Fade Time (0 - 127) |
| 00 07 | 0000 000a | LFO 1 Key Sync (0 - 1) |
| | | OFF, ON |
|-------------+-----------+----------------------------------------------------|
| 00 08 | 0000 0aaa | LFO 2 Waveform (0 - 7) |
| | | SIN, TRI, SAW, SQR, RND, TRP, |
| | | S&H, CHS |
|# 00 09 | 0000 aaaa | |
| | 0000 bbbb | LFO 2 Rate (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 00 0B | 0000 0aaa | LFO 2 Offset (0 - 4) |
| | | -100, -50, 0, +50, +100 |
| 00 0C | 0aaa aaaa | LFO 2 Delay Time (0 - 127) |
| 00 0D | 0000 00aa | LFO 2 Fade Mode (0 - 3) |
| | | ON-IN, ON-OUT, OFF-IN, OFF-OUT |
| 00 0E | 0aaa aaaa | LFO 2 Fade Time (0 - 127) |
| 00 0F | 0000 000a | LFO 2 Key Sync (0 - 1) |
| | | OFF, ON |
|-------------+-----------+----------------------------------------------------|
| 00 10 | 0000 0aaa | LFO 3 Waveform (0 - 7) |
| | | SIN, TRI, SAW, SQR, RND, TRP, |
| | | S&H, CHS |
|# 00 11 | 0000 aaaa | |
| | 0000 bbbb | LFO 3 Rate (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 00 13 | 0000 0aaa | LFO 3 Offset (0 - 4) |
| | | -100, -50, 0, +50, +100 |
| 00 14 | 0aaa aaaa | LFO 3 Delay Time (0 - 127) |
| 00 15 | 0000 00aa | LFO 3 Fade Mode (0 - 3) |
| | | ON-IN, ON-OUT, OFF-IN, OFF-OUT |
| 00 16 | 0aaa aaaa | LFO 3 Fade Time (0 - 127) |
| 00 17 | 0000 000a | LFO 3 Key Sync (0 - 1) |
| | | OFF, ON |
|-------------+-----------+----------------------------------------------------|
| 00 18 | 0000 0aaa | LFO 4 Waveform (0 - 7) |
| | | SIN, TRI, SAW, SQR, RND, TRP, |
| | | S&H, CHS |
|# 00 19 | 0000 aaaa | |
| | 0000 bbbb | LFO 4 Rate (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 00 1B | 0000 0aaa | LFO 4 Offset (0 - 4) |
| | | -100, -50, 0, +50, +100 |
| 00 1C | 0aaa aaaa | LFO 4 Delay Time (0 - 127) |
| 00 1D | 0000 00aa | LFO 4 Fade Mode (0 - 3) |
| | | ON-IN, ON-OUT, OFF-IN, OFF-OUT |
