Roland V-Synth Supplementary Guide

16
MIDI Implementation
| | | REST, 1 - 127, TIE |
|# 00 2C | 0000 aaaa | |
| | 0000 bbbb | Step 22 Velocity (0 - 128) |
| | | REST, 1 - 127, TIE |
|# 00 2E | 0000 aaaa | |
| | 0000 bbbb | Step 23 Velocity (0 - 128) |
| | | REST, 1 - 127, TIE |
|# 00 30 | 0000 aaaa | |
| | 0000 bbbb | Step 24 Velocity (0 - 128) |
| | | REST, 1 - 127, TIE |
|# 00 32 | 0000 aaaa | |
| | 0000 bbbb | Step 25 Velocity (0 - 128) |
| | | REST, 1 - 127, TIE |
|# 00 34 | 0000 aaaa | |
| | 0000 bbbb | Step 26 Velocity (0 - 128) |
| | | REST, 1 - 127, TIE |
|# 00 36 | 0000 aaaa | |
| | 0000 bbbb | Step 27 Velocity (0 - 128) |
| | | REST, 1 - 127, TIE |
|# 00 38 | 0000 aaaa | |
| | 0000 bbbb | Step 28 Velocity (0 - 128) |
| | | REST, 1 - 127, TIE |
|# 00 3A | 0000 aaaa | |
| | 0000 bbbb | Step 29 Velocity (0 - 128) |
| | | REST, 1 - 127, TIE |
|# 00 3C | 0000 aaaa | |
| | 0000 bbbb | Step 30 Velocity (0 - 128) |
| | | REST, 1 - 127, TIE |
|# 00 3E | 0000 aaaa | |
| | 0000 bbbb | Step 31 Velocity (0 - 128) |
| | | REST, 1 - 127, TIE |
|# 00 40 | 0000 aaaa | |
| | 0000 bbbb | Step 32 Velocity (0 - 128) |
| | | REST, 1 - 127, TIE |
|-------------+----------------------------------------------------------------|
| 00 00 00 42 | Total Size |
+------------------------------------------------------------------------------+
❍Patch Step Modulator
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 | 0000 000a | Master Switch (0 - 1) |
| | | OFF, ON |
| 00 01 | 0000 00aa | Key Sync (0 - 2) |
| | | OFF, PART, VOICE |
|-------------+-----------+----------------------------------------------------|
| 00 02 | 0000 000a | Track 1 Switch (0 - 1) |
| | | OFF, ON |
| 00 03 | 0000 000a | Track Loop Switch (0 - 1) |
| | | OFF, ON |
| 00 04 | 0000 000a | Track 1 Type (0 - 1) |
| | | STEP, SMOOTH |
| 00 05 | 0000 0aaa | Track 1 Grid (0 - 5) |
| | | QUARTER, 8TH, 8TH-T, 16TH, |
| | | 16TH-T, 32TH |
| 00 06 | 0000 aaaa | Track 1 End Point (0 - 15) |
| | | 1 - 16 |
| 00 07 | 0000 0aaa | Track 1 Direction (0 - 5) |
| | | FWD1, FWD2, FWD3, BWD1, BWD2, BWD3 |
| 00 08 | 0000 aaaa | Track 1 Zone (0 - 15) |
| | | 1 - 16 |
| 00 09 | 0aaa aaaa | Track 1 Destination (0 - 71) |
| | | OSC1+2-PIT-CRS, OSC1+2-PIT-FINE, PORTA-TIME, |
| | | OSC1-PIT-CRS, OSC1-PIT-FINE, |
| | | OSC1-PITCH, OSC1-PENV-DPT, |
| | | OSC1-TIME/PW, OSC1-TENV-DPT, |
| | | OSC1-FORMA/FAT, OSC1-FENV-DPT, |
| | | OSC1-LFO-RATE, OSC1-LFO-PCH, OSC1-LFO-TM/PW, |
| | | OSC1-LFO-FR/FT, OSC1-LFO-LVL, |
| | | OSC1-LVL, |
| | | OSC2-PIT-CRS, OSC2-PIT-FINE, |
| | | OSC2-PITCH, OSC2-PENV-DPT, |
| | | OSC2-TIME/PW, OSC2-TENV-DPT, |
| | | OSC2-FORMA/FAT, OSC2-FENV-DPT, |
| | | OSC2-LFO-RATE, OSC2-LFO-PCH, OSC2-LFO-TM/PW, |
| | | OSC2-LFO-FR/FT, OSC2-LFO-LVL, |
| | | OSC2-LVL, |
| | | CSM1-PRM1, CSM1-PRM2, |
| | | CSM1-ENV1-ATK, CSM1-ENV1-DCY, |
| | | CSM1-ENV1-SUS, CSM1-ENV1-REL, |
| | | CSM1-ENV2-ATK, CSM1-ENV2-DCY, |
| | | CSM1-ENV2-SUS, CSM1-ENV2-REL, |
| | | CSM1-LFO-RATE, CSM1-LFO-PRM1, CSM1-LFO-PRM2, |
| | | CSM2-PRM1, CSM2-PRM2, |
| | | CSM2-ENV1-ATK, CSM2-ENV1-DCY, |
| | | CSM2-ENV1-SUS, CSM2-ENV1-REL, |
| | | CSM2-ENV2-ATK, CSM2-ENV2-DCY, |
| | | CSM2-ENV2-SUS, CSM2-ENV2-REL, |
| | | CSM2-LFO-RATE, CSM2-LFO-PRM1, CSM2-LFO-PRM2, |
| | | TVA-LVL, TVA-PAN, |
| | | TVA-ENV-ATK, TVA-ENV-DCY, |
| | | TVA-ENV-SUS, TVA-ENV-REL, |
| | | TVA-LFO-RATE, TVA-LFO-LVL, TVA-LFO-PAN, |
| | | MFX-SEND, CHO-SEND, REV-SEND, |
| | | MFX-PRM1, MFX-PRM2, MFX-PRM3 |
| 00 0A | 0aaa aaaa | Track 1 Step 01 Value (1 - 127) |
| | | -63 - +63 |
| 00 0B | 0aaa aaaa | Track 1 Step 02 Value (1 - 127) |
| | | -63 - +63 |
| 00 0C | 0aaa aaaa | Track 1 Step 03 Value (1 - 127) |
| | | -63 - +63 |
| 00 0D | 0aaa aaaa | Track 1 Step 04 Value (1 - 127) |
| | | -63 - +63 |
| 00 0E | 0aaa aaaa | Track 1 Step 05 Value (1 - 127) |
| | | -63 - +63 |
| 00 0F | 0aaa aaaa | Track 1 Step 06 Value (1 - 127) |
| | | -63 - +63 |
| 00 10 | 0aaa aaaa | Track 1 Step 07 Value (1 - 127) |
| | | -63 - +63 |
| 00 11 | 0aaa aaaa | Track 1 Step 08 Value (1 - 127) |
| | | -63 - +63 |
| 00 12 | 0aaa aaaa | Track 1 Step 09 Value (1 - 127) |
| | | -63 - +63 |
| 00 13 | 0aaa aaaa | Track 1 Step 10 Value (1 - 127) |
| | | -63 - +63 |
| 00 14 | 0aaa aaaa | Track 1 Step 11 Value (1 - 127) |
| | | -63 - +63 |
| 00 15 | 0aaa aaaa | Track 1 Step 12 Value (1 - 127) |
| | | -63 - +63 |
| 00 16 | 0aaa aaaa | Track 1 Step 13 Value (1 - 127) |
| | | -63 - +63 |
| 00 17 | 0aaa aaaa | Track 1 Step 14 Value (1 - 127) |
| | | -63 - +63 |
| 00 18 | 0aaa aaaa | Track 1 Step 15 Value (1 - 127) |
| | | -63 - +63 |
| 00 19 | 0aaa aaaa | Track 1 Step 16 Value (1 - 127) |
| | | -63 - +63 |
|-------------+-----------+----------------------------------------------------|
| 00 1A | 0000 000a | Track 2 Switch (0 - 1) |
| | | OFF, ON |
| 00 1B | 0000 000a | Track Loop Switch (0 - 1) |
| | | OFF, ON |
| 00 1C | 0000 000a | Track 2 Type (0 - 1) |
| | | STEP, SMOOTH |
| 00 1D | 0000 0aaa | Track 2 Grid (0 - 5) |
| | | QUARTER, 8TH, 8TH-T, 16TH, |
| | | 16TH-T, 32TH |
| 00 1E | 0000 aaaa | Track 2 End Point (0 - 15) |
| | | 1 - 16 |
| 00 1F | 0000 0aaa | Track 2 Direction (0 - 5) |
| | | FWD1, FWD2, FWD3, BWD1, BWD2, BWD3 |
| 00 20 | 0000 aaaa | Track 2 Zone (0 - 15) |
| | | 1 - 16 |
| 00 21 | 0aaa aaaa | Track 2 Destination (0 - 71) |
| | | OSC1+2-PIT-CRS, OSC1+2-PIT-FINE, PORTA-TIME, |
| | | OSC1-PIT-CRS, OSC1-PIT-FINE, |
| | | OSC1-PITCH, OSC1-PENV-DPT, |
| | | OSC1-TIME/PW, OSC1-TENV-DPT, |
| | | OSC1-FORMA/FAT, OSC1-FENV-DPT, |
| | | OSC1-LFO-RATE, OSC1-LFO-PCH, OSC1-LFO-TM/PW, |
| | | OSC1-LFO-FR/FT, OSC1-LFO-LVL, |
| | | OSC1-LVL, |
| | | OSC2-PIT-CRS, OSC2-PIT-FINE, |
| | | OSC2-PITCH, OSC2-PENV-DPT, |
| | | OSC2-TIME/PW, OSC2-TENV-DPT, |
| | | OSC2-FORMA/FAT, OSC2-FENV-DPT, |
| | | OSC2-LFO-RATE, OSC2-LFO-PCH, OSC2-LFO-TM/PW, |
| | | OSC2-LFO-FR/FT, OSC2-LFO-LVL, |
| | | OSC2-LVL, |
| | | CSM1-PRM1, CSM1-PRM2, |
| | | CSM1-ENV1-ATK, CSM1-ENV1-DCY, |
| | | CSM1-ENV1-SUS, CSM1-ENV1-REL, |
| | | CSM1-ENV2-ATK, CSM1-ENV2-DCY, |
| | | CSM1-ENV2-SUS, CSM1-ENV2-REL, |
| | | CSM1-LFO-RATE, CSM1-LFO-PRM1, CSM1-LFO-PRM2, |
| | | CSM2-PRM1, CSM2-PRM2, |
| | | CSM2-ENV1-ATK, CSM2-ENV1-DCY, |
| | | CSM2-ENV1-SUS, CSM2-ENV1-REL, |
| | | CSM2-ENV2-ATK, CSM2-ENV2-DCY, |
| | | CSM2-ENV2-SUS, CSM2-ENV2-REL, |
| | | CSM2-LFO-RATE, CSM2-LFO-PRM1, CSM2-LFO-PRM2, |
| | | TVA-LVL, TVA-PAN, |
| | | TVA-ENV-ATK, TVA-ENV-DCY, |
| | | TVA-ENV-SUS, TVA-ENV-REL, |
| | | TVA-LFO-RATE, TVA-LFO-LVL, TVA-LFO-PAN, |
| | | MFX-SEND, CHO-SEND, REV-SEND, |
| | | MFX-PRM1, MFX-PRM2, MFX-PRM3 |
| 00 22 | 0aaa aaaa | Track 2 Step 01 Value (1 - 127) |
| | | -63 - +63 |
| 00 23 | 0aaa aaaa | Track 2 Step 02 Value (1 - 127) |
| | | -63 - +63 |
| 00 24 | 0aaa aaaa | Track 2 Step 03 Value (1 - 127) |
| | | -63 - +63 |
| 00 25 | 0aaa aaaa | Track 2 Step 04 Value (1 - 127) |
| | | -63 - +63 |
| 00 26 | 0aaa aaaa | Track 2 Step 05 Value (1 - 127) |
| | | -63 - +63 |
| 00 27 | 0aaa aaaa | Track 2 Step 06 Value (1 - 127) |
| | | -63 - +63 |
| 00 28 | 0aaa aaaa | Track 2 Step 07 Value (1 - 127) |
| | | -63 - +63 |
| 00 29 | 0aaa aaaa | Track 2 Step 08 Value (1 - 127) |
| | | -63 - +63 |
| 00 2A | 0aaa aaaa | Track 2 Step 09 Value (1 - 127) |
| | | -63 - +63 |
| 00 2B | 0aaa aaaa | Track 2 Step 10 Value (1 - 127) |
| | | -63 - +63 |
| 00 2C | 0aaa aaaa | Track 2 Step 11 Value (1 - 127) |
| | | -63 - +63 |
| 00 2D | 0aaa aaaa | Track 2 Step 12 Value (1 - 127) |
| | | -63 - +63 |
| 00 2E | 0aaa aaaa | Track 2 Step 13 Value (1 - 127) |
| | | -63 - +63 |
| 00 2F | 0aaa aaaa | Track 2 Step 14 Value (1 - 127) |
| | | -63 - +63 |
| 00 30 | 0aaa aaaa | Track 2 Step 15 Value (1 - 127) |
| | | -63 - +63 |
| 00 31 | 0aaa aaaa | Track 2 Step 16 Value (1 - 127) |
| | | -63 - +63 |
|-------------+-----------+----------------------------------------------------|
| 00 32 | 0000 000a | Track 3 Switch (0 - 1) |
| | | OFF, ON |
| 00 33 | 0000 000a | Track Loop Switch (0 - 1) |
| | | OFF, ON |
| 00 34 | 0000 000a | Track 3 Type (0 - 1) |
| | | STEP, SMOOTH |
| 00 35 | 0000 0aaa | Track 3 Grid (0 - 5) |
| | | QUARTER, 8TH, 8TH-T, 16TH, |
| | | 16TH-T, 32TH |
| 00 36 | 0000 aaaa | Track 3 End Point (0 - 15) |
| | | 1 - 16 |
| 00 37 | 0000 0aaa | Track 3 Direction (0 - 5) |
| | | FWD1, FWD2, FWD3, BWD1, BWD2, BWD3 |
| 00 38 | 0000 aaaa | Track 3 Zone (0 - 15) |
| | | 1 - 16 |
| 00 39 | 0aaa aaaa | Track 3 Destination (0 - 71) |
| | | OSC1+2-PIT-CRS, OSC1+2-PIT-FINE, PORTA-TIME, |
| | | OSC1-PIT-CRS, OSC1-PIT-FINE, |
| | | OSC1-PITCH, OSC1-PENV-DPT, |
| | | OSC1-TIME/PW, OSC1-TENV-DPT, |
| | | OSC1-FORMA/FAT, OSC1-FENV-DPT, |
| | | OSC1-LFO-RATE, OSC1-LFO-PCH, OSC1-LFO-TM/PW, |
| | | OSC1-LFO-FR/FT, OSC1-LFO-LVL, |
| | | OSC1-LVL, |
| | | OSC2-PIT-CRS, OSC2-PIT-FINE, |
| | | OSC2-PITCH, OSC2-PENV-DPT, |
| | | OSC2-TIME/PW, OSC2-TENV-DPT, |
| | | OSC2-FORMA/FAT, OSC2-FENV-DPT, |
| | | OSC2-LFO-RATE, OSC2-LFO-PCH, OSC2-LFO-TM/PW, |
| | | OSC2-LFO-FR/FT, OSC2-LFO-LVL, |
| | | OSC2-LVL, |
| | | CSM1-PRM1, CSM1-PRM2, |
| | | CSM1-ENV1-ATK, CSM1-ENV1-DCY, |
| | | CSM1-ENV1-SUS, CSM1-ENV1-REL, |
| | | CSM1-ENV2-ATK, CSM1-ENV2-DCY, |
| | | CSM1-ENV2-SUS, CSM1-ENV2-REL, |
| | | CSM1-LFO-RATE, CSM1-LFO-PRM1, CSM1-LFO-PRM2, |
| | | CSM2-PRM1, CSM2-PRM2, |
| | | CSM2-ENV1-ATK, CSM2-ENV1-DCY, |
| | | CSM2-ENV1-SUS, CSM2-ENV1-REL, |
| | | CSM2-ENV2-ATK, CSM2-ENV2-DCY, |
| | | CSM2-ENV2-SUS, CSM2-ENV2-REL, |
| | | CSM2-LFO-RATE, CSM2-LFO-PRM1, CSM2-LFO-PRM2, |
| | | TVA-LVL, TVA-PAN, |
| | | TVA-ENV-ATK, TVA-ENV-DCY, |
| | | TVA-ENV-SUS, TVA-ENV-REL, |
| | | TVA-LFO-RATE, TVA-LFO-LVL, TVA-LFO-PAN, |
| | | MFX-SEND, CHO-SEND, REV-SEND, |
| | | MFX-PRM1, MFX-PRM2, MFX-PRM3 |
| 00 3A | 0aaa aaaa | Track 3 Step 01 Value (1 - 127) |
| | | -63 - +63 |
| 00 3B | 0aaa aaaa | Track 3 Step 02 Value (1 - 127) |
| | | -63 - +63 |
| 00 3C | 0aaa aaaa | Track 3 Step 03 Value (1 - 127) |
| | | -63 - +63 |
| 00 3D | 0aaa aaaa | Track 3 Step 04 Value (1 - 127) |
| | | -63 - +63 |
| 00 3E | 0aaa aaaa | Track 3 Step 05 Value (1 - 127) |
| | | -63 - +63 |
| 00 3F | 0aaa aaaa | Track 3 Step 06 Value (1 - 127) |
| | | -63 - +63 |
| 00 40 | 0aaa aaaa | Track 3 Step 07 Value (1 - 127) |
| | | -63 - +63 |

Roland V-Synth Specifications

General

Arpeggiator	Yes
Velocity Sensitivity	Yes
Aftertouch	Yes
Vocoder	Yes
USB	No
Keyboard	61 keys (velocity and aftertouch sensitive)
Effects	Chorus, Delay, Reverb, Distortion, Flanger, Phaser
Sampling	Yes
Display	320x240 pixel color LCD
MIDI	In/Out/Thru
Type	Synthesizer
LFO	Yes
Storage	SmartMedia card
Outputs	Stereo
Headphones	Yes
Power Supply	AC
Inputs	Stereo Line, Microphone
Audio Inputs	Stereo Line, Mic
