Roller Comet User Manual

1. TechnicalData
Usefortheintendedpurpose
WARNING
Use ROLLER’S Comet properly for hard and soft soldering, heating, annealing,
burning off, melting, thawing, shrinking and similar thermal processes with acetylene.
All other uses are not for the intended purpose and are prohibited.
1.1. Article numbers
ROLLER’S Comet Turbo soldering torch acetylene
for brazing and softsoldering. In cardboard box. 161010
Steel case 160160
1.2. Purpose of use
The ROLLER’S Comet is an acetylene torch which can be used for brazing
and soft soldering, heating, annealing, burning off, melting, thawing,
shrinking and similar thermal processes.
1.3. Permitted gas Acetylene
1.4. Operating gas pressure 1bar(14psi)
1.5. Gas consumption 360 l/h
1.6. Output 20000kJ/h(19000BTU)
1.7. Flame temperature 2500°C(4500°F)
1.8. Noise data
 Workplacerelatednoiselevel 84dB(A)
2. Preparations for Use
2.1. Gas connection
Secure the gas cylinder against falling over. Use an adjustable pressure regu-
lator(0to2.5bar)andashbackarrester.Connectanapprovedgashoseline
foracetylenetothegascylinderrespectivelyashbackarresterandthreaded
socket(3)oftheacetylenetorch.
WARNING
 BSPP⅜”left-handthreadsineachcase.Setthegaspressureto1bar.Check
the system for leaks.
3. Operation
CAUTION
 Wearprotectiveglasses!
3.1. Solderingtorchacetylene
Open the gas cylinder valve; if necessary set the gas pressure as des cribed
under1.Theintegralvalveinthetorchisopenedbyoperatingthetrigger(1).
Simultaneously,thesparkgenerator(piezoigniter)projectsasparkintothe
torch pipe, igniting the gas. On ignition, a loud report is produced; this has no
effect on the functioning of the apparatus. Following a new connection or
reconnection to a gas cylinder, it may be necessary to operate the trigger
repeatedly until the air has been expelled from the hoseline.
When the trigger is released, the valve in the torch closes, cutting off the gas
supply,andtheamegoesout.
 Ifthelockingbutton(2)ispressedwhenthetriggerisoperated,thetriggerwill
stay on and the torch will continue to remain lit. When the trigger is operated
again, the locking button will be released. When the trigger itself is then released,
theamewillgoout.
For brazing operations,thetipsofthecircularameshouldtouchthework-
piece. For soft soldering operations,thetipsoftheamescanbeheldata
distance of 10 – 30 mm from the workpiece, depending on the size of the pipe.
NOTICE
 Donotreducethegaspressureandalwayspressthetrigger(1)tillthevery
end,otherwise,duetoareducedame,thetorchpipeandsparkgenerator
may be damaged.
CAUTION
When the torch is no longer required, close the gas cylinder valve and allow
the residual gas in the hoseline and torch to burn off.
3.2. Soldering material
For brazing operations,useROLLER’SLotP6.Copperpipesandttings
mustnotbetreatedwithuxbutintheirbaremetalstate.Forothermaterials,
suchasbrass,itmaybenecessarytouseux.
For soft soldering operations, use ROLLER’S Lot Cu 3. Copper pipes and
ttingsmustbetreatedasbaremetal.Topreparethesolderedarea,apply
ROLLER’S Paste Cu 3 to the pipe section. This paste contains soldering powder
andux.Theadvantageofthepasteliesinthefactthatthetemperaturerequired
forsolderingcanbeidentiedbyachangeofcolourintheheatedpaste,thus
ensuringthatthesolderedjointisproperlylled.Inanycase,however,ROLL-
ER’S Lot Cu 3 must be inserted afterwards. ROLLER’S Lot Cu3 and ROLLER’S
Paste Cu 3 have been specially developed for drinking water pipes and comply
withthespecicationslaiddownbytheGermanFederationofGasandSanitary
Engineers(GW2andGW7)andtherelevantDINstandards.
4. Maintenance
Maintenance and repair operations on the torch must not be carried out other
thanbyqualiedpersonnelorROLLERaftersalesservicecentres.Norepairs
ormodicationstothetorcharepermittedbyunauthorisedpersons.
Before undertaking any maintenance or repair operations, close the valve on
the gas cylinder and allow any residual gas in the hose and torch to burn off.
 Toreplacethetorchnozzle,torchpipeorsparkgenerator,unscrewtheve
screws from the housing and remove the upper part of the housing. Now remove
the torch from the lower part of the housing. Pull off the torch pipe and nozzle
retainer. Replace the nozzle retainer with torch nozzle, torch pipe or spark
generator.
5. Action in Case of Trouble
5.1. Fault: Torchwillnotigniteorproducesweakame.
Cause: ● Gas cylinder empty.
● Gas cylinder valve closed.
● Pressure incorrectly set.
● Hose defective.
●  Torchnozzleobstructed(see4.).
5.2. Fault: Torchwillnotigniteautomatically(butcanbelitwithe.g.amatch).
Cause: ●  Sparkgenerator(piezoigniter)defective.
6. Manufacturer’sWarranty
The warranty period shall be 12 months from delivery of the new product to the
rstuser.Thedateofdeliveryshallbedocumentedbythesubmissionofthe
original purchase documents, which must include the date of purchase and the
designation of the product. All functional defects occurring within the warranty
period, which are clearly the consequence of defects in production or materials,
will be remedied free of charge. The remedy of defects shall not extend or
renew the warranty period for the product. Damage attributable to natural wear
and tear, incorrect treatment or misuse, failure to observe the operational
instructions, unsuitable operating materials, excessive demand, use for unau-
thorized purposes, interventions by the customer or a third party or other
reasons, for which ROLLER is not responsible, shall be excluded from the
warranty
Services under the warranty may only be provided by customer service stations
authorized for this purpose by ROLLER. Complaints will only be accepted if
the product is returned to a customer service station authorized by ROLLER
without prior interference in an unassembled condition. Replaced products and
parts shall become the property of ROLLER.
The user shall be responsible for the cost of shipping and returning the product.
The legal rights of the user, in particular the right to make claims against the
seller under the warranty terms, shall not be affected. This manufacturer’s
warranty only applies for new products which are purchased in the European
Union, in Norway or in Switzerland.
This warranty is subject to German law with the exclusion of the United Nations
ConventiononContractsfortheInternationalSalesofGoods(CISG).
7. Spare parts lists
For spare parts lists, see www.albert-roller.de →Downloads→Partslists.
eng eng
5

Roller Comet Specifications

General

Brand	Roller
Model	Comet
Category	Soldering Gun
Language	English
