Installation guidelines
• The standard cable routing for the direct drive should be laid on the edge of the pool with a
connection box; this must be accessible at all times.
• The length of the conduit between the drive and connection box should be max. 3.5 m.
• The supply cable between the controller and distribution box must correspond to the
characteristics specified in Rollo Solar’s supply table (see the section ‘Rollo Solar supply
table’). We recommend using the original extension cable, article no. 6100-0023.
• If installations do not correspond to these installation guidelines, additional costs may be
incurred in the event of a motor replacement.
Caution! The installation of the system must be performed by a qualified specialist in accordance
with the associated drawings and installation instructions.
Please ensure that only special tools (VA stainless steel) are used during the installation.
Electrical work
• Please observe the following with respect to all electrical work:
Electrical connections may only be carried out by a skilled electrician.
• The electrical installations at the building site must correspond to the respective protection
provisions.
• The mains plug must be disconnected prior to all work on the drive, controller or
transformer.
• Prevent electronic components from coming into contact with water,
as this can result in damage involving short circuits.
• Prevent external voltage on the transformer and/or the controller, as this may destroy the
electronics.
Caution! A maximum of 24 VOLT DC, 500 mA can be connected to the ‘POS AUF’ and ‘POS
ZU’ position reports. Exceeding these values will result in irreparable damage to the
electronic components.
