CONNECTING THE KEY SWITCH
(1) ‘STOP’ operating switch
(2) ‘AUF’ (OPEN) operating switch
(3) ‘ZU’ (CLOSED) operating switch
(4) Key cylinder
Please note: This operating switch is available as shown here, as well as with an
emergency stop button. The model is available in both a flush mounted version and in
a surface mounted version. It is operated using the provided key.
