Part No 4801-5156 Rev 1-2017 RollSeal SC-325 & SC-650 Controllers Page 47
15 Replacement Parts and Optional Accessories
15.1 SC-325 Controller
SC-325 Controls, Parts, and Accessories
Part Number Description Notes
Controller
6607-8057 SC-325-V01-115 Use with RS-500 Doors ONLY
6607-8056 SC-325-V02-0 (Includes V2 Drive & Brake Module) Use with RS-500 Doors ONLY
6607-8058
SC-325-V01-000-W01 (Includes W01 Switch Wiring Option with
Conduit)
Use with RS-500 Doors ONLY
6607-8060 SC-325-V01-115-PLUS (Includes Prewired Controller) Use with RS-500 Doors ONLY
6607-8061 SC-325-V01-230-PLUS (Includes Prewired Controller) Use with RS-500 Doors ONLY
Drive Board Assemblies
6407-6082
Use with SC-325 Controller 6607-8057, 6607-8058,
6607-8060, and 6607-8061
/PCB AC DriveKBVF-22D w/QA V1 (V1 Drive)
Use with SC-325 Controllers ONLY.
6407-6083
Use with SC-325 Controller 6607-8056
/PCB AC DriveKBVF-22D w/QA V2 (V2 Drive)
Use with SC-325 Controllers ONLY.
1902-4701 Drive Cable Assembly
Chips
3701-6069 PIC SC-325 RS Door Control V0.xx (Processor) Use with SC-325 Controllers ONLY.
3540-0143 Double ‘E’ Chip
Fuses
3010-3001 FUSE 1.2 AMP 5mmX20mm slow blow (F1) Located on PCB 154
3010-2140 FUSE 10 AMP 1/4X1-1/4 TD Main Fuse (Black Holder) Use with SC-325 Controllers ONLY.
Brake Module & Rectifier
6407-6088 Brake Module (Use with SC-325 Controller 6607-8056)
3017-3052 Brake Rectifier (Use with 115 VAC Doors)
3017-3050 Brake Rectifier (Use with 230 VAC Doors)
Switches
3001-2865 Main Power Switch w/toggle tabs
Door Assembly
6407-0618 /DOOR ASSY SC-325 Use with SC-325 Controllers ONLY.
