GB
14
Hook buckle tongues 19 into the rubber
loops 29 (are not available on all covers)
on the cover on the left and right side.
Fold the crotch belt pad 21 and buckle 17
towards you.
Place the child into child seat.
Take the buckle tongues 19 left and right
from the rubber loops 29 on the cover.
29
21
17
Put the shoulder belts 10 over the
shoulders of the child. (Do not twist the
belts.)
Put both buckle tongues 19 together …
19
10
…and insert them into the buckle 17.
Listen for the audible "click".
Tighten harness (refer to 4.3) until they lie
close to the body of the child.
17
4.5. Function of the buckle
The function of the buckle is very important for the safety of your child.
Functional faults relating to the buckle are mostly attributable to accumulations
of dust and dirt.
Functional Problem
• The buckle tongues are only slowly ejected when pressing the red release
button.
• The tongues will no longer lock home (are ejected again).
• The buckle tongues engage without the audible "click".
part number: 09163186 ( GM ) / 93181287 ( Vauxhall )
