GB
10
3.3. without ISOFIX fastening (universal)
After adjusting the shoulder belts (refer to 4.1) place the child seat into the
vehicle seat. Fasten the child seat with the vehicle 3-point-seat belt as follows:
Place the child seat onto the cover side
(locking mechanism will disengage).
Push the ISOFIX connectors 3 at the
green lever 2 completely into the seat
base.
2
3
Clip the connector protection 33 onto the
connectors 3.
33
3
Pull the belt out and guide it through the
belt guides 7.
7
Engage buckle tongue in buckle housing.
* The connector protection 33 protects the ISOFIX connectors 3
when they are not used. Additionally it prevents the car seat from
damage when the child seat is fixed with the 3-point belt.
part number: 09163186 ( GM ) / 93181287 ( Vauxhall )
